Littelfuse ALT-115-X-SW - The ALT alternating relays are used to alternate between two loads. The ALT is commonly used in duplex pumping applications to balance the runtime of both pumps. The ALT-S is used in single high-level float applications. When the float switch opens, the alternating relay changes state, forcing the other pump to run the next time the float closes. All ALT relays have a built-in debounce feature that prevents the relay from changing state if the switch or float contact bounces momentarily. The ALT-X has an internal cross-connected relay and is used in dual high-level float applications. These floats are commonly referred to as lead and lag floats. The pumps alternate as in the ALT-S version but the crossconnected relay configuration allows both pumps to run simultaneously when both the lead and lag floats are closed. These relays are also available with a built-in switch (SW option) that is used to manually force one of the pumps to run every time the float switch is closed. This is helpful when a pump has been removed for repair or for test purposes. In the case of the ALT-X-SW, the switch essentially forces one pump to be the lead pump, while still allowing the second to run when both floats are closed. Must use the OT08PC socket for UL Rating!

Littelfuse ALT-115-X-SW The ALT alternating relays are used to alternate between two loads. The ALT is commonly…

Alternate Item Number: ALT115-X-SW

UPC: 079458991338

Documents & Media
BrochureSpecification SheetUser Manual

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The Littelfuse ALT-115-X-SW is an 8-pin plug-in alternating relay designed for duplex pumping applications requiring balanced load alternation and manual control. This model integrates an internal cross-connected relay (ALT-X) to enable simultaneous pump operation when both lead and lag floats are closed, while maintaining alternating runtime under normal conditions. The built-in manual override switch (SW option) forces one pump to run on demand—ideal for maintenance, testing, or forced operation scenarios. A debounce circuit prevents false state changes from float switch bounce, ensuring reliable performance. The relay is housed in a compact 8-pin plug-in design, making it suitable for space-constrained control panels. Typical applications include wastewater management, sump pumping, and irrigation systems where pump runtime balancing extends equipment life and prevents uneven wear. The debounce feature ensures stable operation even in environments with vibration or electrical noise. The manual override switch allows technicians to bypass the alternating logic for testing or maintenance without disconnecting wiring. The cross-connected relay configuration in the ALT-X variant ensures both pumps can operate simultaneously when required, improving system flexibility. The ALT-115-X-SW is part of Littelfuse's Protection Relays series, a trusted brand in industrial control solutions.
  • 8-pin plug-in design for easy installation and replacement
  • Internal cross-connected relay (ALT-X) enables simultaneous pump operation when both floats are closed
  • Built-in manual override switch (SW option) for forced pump operation during maintenance or testing
  • Debounce circuit prevents false state changes from float switch bounce
  • Designed for duplex pumping applications in wastewater, sump, and irrigation systems

Specifications

Brand Name
Littelfuse
Connection Type
Socket (OT08PC)
Mounting
DIN rail or Surface mount (plug into OT08-PC socket)
Mounting Type
Socket (OT08PC)
Number Of Poles
DIN rail or surface mount (plug into OT08-PC socket)
Operating Temperature
-40 to 158
Operating Temperature, Maximum
158
Operating Temperature, Minimum
-40
Pickup Voltage
95-125 V
Poles
2P
Series
ALT
Series
ALT Series
Special Features
5YR WARR
Standard
UL/CSA
Sub Brand
Symcom
Voltage Rating
115 VAC
Package Dimensions (L x W x H)
4.13 IN x 2.38 IN x 1.75 IN
Package Dimensions (L x W x H)
104.8 mm x 60.3 mm x 44.5 mm
The ALT alternating relays are used to alternate between two loads. The ALT is commonly used in duplex pumping applications to balance the runtime of both pumps. The ALT-S is used in single high-level float applications. When the float switch opens, the alternating relay changes state, forcing the other pump to run the next time the float closes. All ALT relays have a built-in debounce feature that prevents the relay from changing state if the switch or float contact bounces momentarily. The ALT-X has an internal cross-connected relay and is used in dual high-level float applications. These floats are commonly referred to as lead and lag floats. The pumps alternate as in the ALT-S version but the crossconnected relay configuration allows both pumps to run simultaneously when both the lead and lag floats are closed. These relays are also available with a built-in switch (SW option) that is used to manually force one of the pumps to run every time the float switch is closed. This is helpful when a pump has been removed for repair or for test purposes. In the case of the ALT-X-SW, the switch essentially forces one pump to be the lead pump, while still allowing the second to run when both floats are closed. Must use the OT08PC socket for UL Rating!
