Contact for Pricing
Overview
- 50 kVA capacity for general purpose industrial and light duty loads
- Primary voltage: 380/347V; Secondary voltage: 120/240V
- 50/60 Hz operation with 130°C insulation class and 80°C temperature rise
- High-quality silicon steel laminations and encapsulated coils for durability
- Includes heavy steel mounting feet, SEMS washers, and standard secondary fuse clips
Specifications
Application | HVAC, signals and alarm systems, motor control circuits, lighting and circuit isolation |
Enclosure | Core and Coil |
Frequency Rating | 50 HZ |
Height | 2.6 in |
Length | 2.6 in |
Mounting | Panel |
Special Features | Control transformer for stanard commercial loads without high current inrush, optional finger safe covers are available. |
Standard | csa, ul, ce |
Temperature Rating | Typical 30 Average/ 40 Maximum Deg C |
Type | Tranformer > Dry Type > Control > Open Core and coil |
Wattage | 50 VA |
Width | 3.35 IN |
Package Dimensions (L x W x H) | 2.6 IN x 3.35 IN x 2.6 IN |
Package Dimensions (L x W x H) | 66.04 mm x 85.09 mm x 66.04 mm |
Package Weight (Imperial) | 1.700 L |
Package Weight (Metric) | 0.800 kg |
How to Install the Open Core & Coil Industrial Control Transformer
This guide provides step-by-step instructions for installing and wiring the Open Core & Coil Industrial Control Transformer, ensuring proper setup for optimal performance.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the transformer
Secure the transformer to the mounting surface using appropriately sized mounting screws. Ensure that the hardware used is suitable for the weight of the transformer.
- Connect the voltage links and jumpers
Install the voltage link kit and jumper kits as per the provided wiring instructions. Ensure all connections are tight and secure.
- Wire the transformer
Use 18 AWG to 14 AWG solid wire or 18 AWG to 12 AWG stranded wire for all bare wire connections. If using different wire sizes, utilize ring or spade connectors.
- Torque terminal screws
Tighten all terminal screws to a torque of 12 to 14 inch-lbs to ensure a secure connection.
- Install optional accessories
If applicable, install the optional Fuse Block Adapter Kit by removing the appropriate captive washer screws from the terminal block and using them to secure the fuse block.
- Verify connections
Use a multimeter to check all connections for continuity and proper voltage levels before powering on the transformer.
