Hammond Power EC1X5 - Control Transformer Accessories - Fuse Kit, 250 V, 1.5A, C20
Hammond Power

EC1X5

UPC: 803423004880

Documents & Media
BrochureTechnical Drawing

Contact for Pricing

Overview

The Hammond Power EC1X5 Fuse Kit (SKU: EC1X5) provides essential overcurrent protection for control transformers in industrial and automation applications. This kit includes a 250V, 1.5A fuse, specifically rated for C20 type applications, ensuring precise and reliable performance. Manufactured in France, the EC1X5 is designed to safeguard electrical systems from damaging surges, faults, and overloads, preventing costly downtime and equipment damage. The fuse kit is ideal for use in control panels, automation systems, industrial machinery, and other critical applications where reliable protection is essential. Its compact design and precise specifications ensure seamless integration and dependable operation, meeting stringent safety standards such as IEC and UL requirements. The EC1X5 is a crucial accessory for maintaining the operational integrity and longevity of Hammond Power control transformers, providing consistent and effective protection in demanding industrial environments. With a rated voltage of 250V and a current rating of 1.5A, this fuse kit is engineered for high-performance applications, offering peace of mind and enhanced system reliability.
  • Provides 250V, 1.5A overcurrent protection
  • C20 type fuse rating for specific applications
  • Designed as an accessory for Hammond Power control transformers
  • Ensures reliable protection for industrial electrical systems
  • Manufactured in France

Specifications

Amperage Rating
30 Amp Max.
Application
Add fuse mounting options.
Class
CC, Midget
Color
Metallic
Connection
Snap On
Current Rating
1.5 A
Material
Steel
Mounting
Terminal Block
Operating Temperature
40 Deg C
Phase
1
Series
EC1X5
Special Features
Fuse Holder options
Standard
Not Applicable
Type
Accessories > Fuse Kit or Fuse Holders
Voltage Rating
600 Volt maximum
Voltage Rating
250 V
Wattage
Not Applicable
