Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- 1200 BTU cooling capacity
- 115V operating voltage
- NEMA 3R/4/IP56 protective rating
- RAL 7035 finish
- Dimensions: 29.46" H x 15.55" W x 11.50" D
Specifications
Brand Name | Hammond Mfg. |
Sub Brand | DTS Series |
Voltage Rating | 115 V |
Package Dimensions (L x W x H) | 8.23 IN x 14.3 IN x 16.26 IN |
Package Dimensions (L x W x H) | 20.9042 cm x 36.322 cm x 41.3004 cm |
Package Weight (Imperial) | 42.000 L |
Package Weight (Metric) | 19.051 kg |
Frequently Asked Questions
What is the cooling capacity of the DTS1200A115?
The DTS1200A115 has a cooling capacity of 1,200 BTU/H (350 Watts).
What type of refrigerant does this unit use?
This unit uses R134a refrigerant.
What is the operating voltage for the DTS1200A115?
The rated voltage for the DTS1200A115 is 115 V 60 Hz, with an operating range of 103-127 V.
What is the power consumption of the DTS1200A115?
The power consumption for the DTS1200A115 is 200 W.
What are the minimum and maximum ambient air temperatures for operation?
The unit can operate in a minimum ambient air temperature of +46°F (+8°C) and a maximum of +125°F (+52°C).
Does the unit come with a power cord and plug?
Yes, the DTS1200A115 comes with a line cord with a plug.
What is the noise level of the unit?
The noise level is less than 62 dB (A).
What NEMA rating does this unit maintain for enclosures?
This unit maintains the enclosure's NEMA 12 rating and is IP 54 rated.
