Fibox ASPHK12 - ARCA JIC Swing Panel Hinge Kit for 12 x 10
Fibox

ASPHK12

Alternate Item Number: 8612033

Contact for Pricing

Overview

The Fibox ARCA JIC Swing Panel Hinge Kit (SKU: ASPHK12) is designed for 12 x 10 inch enclosures. This kit enables the mounting of standard Hoffman junction box and NEMA style panels near the front of an enclosure, facilitating easy access to gauges, switches, and pilot lights. It features heavy-gauge brackets and hinges that are installed by drilling small holes in the enclosure sides and bolting the brackets. External screws are stainless steel, with plated steel internal components. Sealing washers are included to maintain original JIC or NEMA standards post-installation. This kit is not compatible with single-door disconnect enclosures. It is suitable for use in HCLO Type 3R enclosures where the enclosure dimensions (A x B) are 16.00 x 12.00 inches (406 x 305 mm) or smaller.
  • Enables mounting of junction box/NEMA style panels
  • Facilitates easy access to internal components
  • Heavy-gauge brackets and hinges
  • Includes sealing washers to maintain enclosure standards
  • Compatible with HCLO Type 3R enclosures up to 16x12 inches

Specifications

Material
Stainless steel (external screws), plated steel (internal components)
Mounting Type
Swing Panel
Mounting Type
Hinge Mount
NEMA Rating
Type 3R
Series
ARCA JIC
Size
12 x 10
Size
12 x 10 inches
The NNC75X75WH2 Halogen-Free Wide Slot Wiring Duct is used to route, protect, and manage wires near sensitive electronic equipment and in environments where heat resistance or public safety is a concern. UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 95 C (203 F). Halogen-Free, Polyphenylene Oxide (PPO). Mounting holes provided. 2.85" x 2.97" (72.4 mm x 75.4 mm) and 6.6' (2 m) long. Cover included. Color White. 5 pieces per package.

NNC75X75WH2

The NNC75X75WH2 Halogen-Free Wide Slot Wiring Duct is used to route, protect, and manage wires near sensitive electronic equipment and in environments where heat resistance or public safety is a concern. UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 95 C (203 F). Halogen-Free, Polyphenylene Oxide (PPO). Mounting holes provided. 2.85" x 2.97" (72.4 mm x 75.4 mm) and 6.6' (2 m) long. Cover included. Color White. 5 pieces per package.
The NE1.5X4WH6 Halogen-Free Wide Slot Wiring Duct design provides greater rigidity and allows for a wide range of wire/bundle sizes. Upper and lower scorelines for easy finger/sidewall section removal. UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 95 C (203 F). Halogen-Free, Polyphenylene Oxide (PPO). Mounting holes provided. 4.06" x 1.64" (103.1 mm x 41.7 mm) and 6' (1.83 m) long. Cover sold separately. Color White. 6 pieces per package.

NE1.5X4WH6

The NE1.5X4WH6 Halogen-Free Wide Slot Wiring Duct design provides greater rigidity and allows for a wide range of wire/bundle sizes. Upper and lower scorelines for easy finger/sidewall section removal. UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 95 C (203 F). Halogen-Free, Polyphenylene Oxide (PPO). Mounting holes provided. 4.06" x 1.64" (103.1 mm x 41.7 mm) and 6' (1.83 m) long. Cover sold separately. Color White. 6 pieces per package.
2 x 3 Inches Duct Spacer, High Impact Polystyrene Snap-Loc Intermediate Spacer For Use With Nonmetallic Ducts

S289JLN

2 x 3 Inches Duct Spacer, High Impact Polystyrene Snap-Loc Intermediate Spacer For Use With Nonmetallic Ducts
2 x 3 Inches Duct Spacer, High Impact Polystyrene Snap-Loc Base Spacer For Use With Nonmetallic Ducts

S288JLN

2 x 3 Inches Duct Spacer, High Impact Polystyrene Snap-Loc Base Spacer For Use With Nonmetallic Ducts
