Overview
- Stores a single pre-recorded voice message, tone, or melody (up to 30 seconds).
- Reprogrammable content using the 300FP field programmer.
- Configurable for single playback or continuous looping.
- Solid-state, non-volatile memory retains messages during power outages.
- UL and cUL listed for safety compliance.
Specifications
2.25 H x 3.25 W x 0.84 D | IN |
Application | Indoor/Outdoor |
Brand Name | Federal Signal |
Color | White |
Dimensions | 2.25 H x 3.25 W x 0.84 D IN |
Material | Plastic |
Mounting | Plug-In |
Mounting Type | Plug-in |
Operating Temperature | -67° to +150°F (-55° to +66°C) |
Series | SelecTone |
Special Features | Compatible With Any Selectone Unit |
Standard | UL,cUL |
Standard | UL Listed/cUL Listed |
Sub Brand | SelecTone |
Termination | Plug-In |
Tone | Holds Single Pre-recorded Voice Message, Tone or Melody |
Type | Custom Tone Module |
Type | Audible Signals |
Package Dimensions (L x W x H) | 4.5 IN x 4.7 IN x 3 IN |
Package Dimensions (L x W x H) | 11.43 cm x 11.938 cm x 7.62 cm |
Package Weight (Imperial) | 0.100 L |
Package Weight (Metric) | 0.045 kg |
Frequently Asked Questions
What is the primary function of the TM33-SD module?
The TM33-SD card provides custom digital messages in any language. It is a SelecTone® Custom Tone Module.
How to Install the TM33 Custom Message Module
This guide provides step-by-step instructions for installing and configuring the TM33 Custom Message Module for use with SelecTone systems.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Unpack and Inspect the TM33
Carefully unpack the TM33 module and inspect it for any damage that may have occurred during transit. If damaged, file a claim with the carrier.
- Mount the TM33 Module
Securely mount the TM33 module into the edge connector of the SelecTone speaker/amplifier or control unit. Ensure that the module is properly seated and that there are no obstructions in front of the speaker.
- Configure the Message Playback
Remove the TM33 from the connector and unscrew the cover to access the circuit board. Locate the JP connector and move the mini-jumper from the 'C' position to the 'S' position to enable single playback of the message.
- Reassemble the TM33 Module
Replace the cover of the TM33 module by securing it with the four screws and washers. Ensure that the washers are positioned correctly between the circuit board and the enclosure.
- Test the Installation
Activate the SelecTone unit to test the TM33 module and ensure it operates as intended. Verify that the message plays correctly according to the configured settings.
