500-120-1

The 500-120-1 vibrating mechanism operates on 120VAC.

The 500-120-1 mechanism draws 0.08 amps during operation.

The recommended duty cycle for the 500-120-1 mechanism is 5 minutes ON followed by 5 minutes OFF.

The 500-120-1 mechanism has dimensions of 4.0 inches height, 4.0 inches width, and 2.13 inches depth.

The net weight of the 500-120-1 mechanism is 1.0 lbs (0.45 kg), with a shipping weight of 1.1 lbs (0.5 kg).

The Model 500 mechanism, which includes the 500-120-1, is CSA Certified, UL Listed, and cUL Listed.

The 500-120-1 mechanism is compatible with A4 (4 inches dia.), A6 (6 inches dia.), and A10 (10 inches dia.) gong models.

No, a gong model must be ordered and specified with the mechanism to form a complete unit that produces sound.

Yes, an optional weatherproof back box (WB) is available, providing a Type 3R enclosure for Vibratone bells.

Vibrating bells produce a continuous ringing sound when voltage is applied.
