Contact for Pricing
Overview
- 8 individually galvanically isolated digital output channels
- Operates with 24-230V AC/DC
- Maximum switching current of 3A per channel
- Normally closed (NC) relay operation
- Requires compatible Module Termination Unit (TU811, TU813, TU831, TU836, TU837, TU851)
Specifications
CE mark | Yes |
Connection Type | Galvanically isolated channels |
Corrosion protection | ISA-S71.04: G3 |
Current consumption +24 V external | 0 |
Current consumption +24 V Modulebus | 140 mA |
Current consumption +5 V Modulebus | 60 mA |
Current limiting | Can be current limited by the MTU |
Current Rating | 3 A per channel |
Current Rating | 3 A |
Depth | 102 mm (4.01"), 111 mm (4.37") including connector |
Dielectric test voltage | 2000 V a.c. |
Electrical safety | EN 61010-1, UL 61010-1, EN 61010-2-201, UL 61010-2-201 |
EMC | EN 61000-6-4, EN 61000-6-2 |
Equipment class | Class I according to IEC 61140; (earth protected) |
HART | No |
Height | 119 mm (4.7") |
High integrity | No |
Intrinsic safety | No |
Isolation | Individually isolated, channel-to-channel and to circuit common |
Marine certification | ABS, BV, DNV, LR |
Max ambient temperature | 55C (131F), for vertical mounting in compact MTU 40C (104F) |
Maximum field cable length | 600 meters (656 yards) |
Mechanical operating conditions | IEC/EN 61131-2 |
Mechanics | S800 |
Number of channels | 8 |
Overvoltage categories | IEC/EN 60664-1, EN 50178 |
Poles | 8 |
Pollution degree | Degree 2, IEC 60664-1 |
Power dissipation | Typ. 2.9 W |
Protection class | IP20 according to IEC 60529 |
Rated insulation voltage | 250 V |
Redundancy | No |
Relative humidity | 5 to 95%, non-condensing |
RoHS compliance | EU RoHS, UAE RoHS, CN RoHS |
Series | DO821 |
Signal specification | 230 V a.c./d.c. (5-250 V a.c./d.c.), 3 A |
Signal type | Relay (NC) |
Size | 45mm(W) x 102mm(D) x 119mm(H) |
Size | 45mm W x 102mm D (111mm with connector) x 119mm H |
SOE | No |
Temperature, Operating | 0 to +55C (+32 to +131F), approvals are issued for +5 to +55C |
Temperature, Storage | -40 to +70C (-40 to +158F) |
Type | Digital Output |
Voltage Rating | 24-230 V AC/DC |
WEEE compliance | DIRECTIVE/2012/19/EU |
Weight | 0.23 kg (0.5 lbs.) |
Width | 45 mm (1.77") |
2TLA020070R4700
