ABB Low Voltage Drives 68324963 R7 bottom exit pedestal
UPC: 662348000090
Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
The ABB R7 bottom exit pedestal (SKU 68324963) is a specialized component for ABB low voltage drives. It features failsafe bi-directional cylinder-lift terminals at the top and bottom for reliable electrical connections. For currents exceeding 63 A, cage terminals are incorporated. Terminal sizes accommodate cables up to 25/25 mm² (IEC) or 18-4 AWG (UL/CSA up to 63 A), and busbar connections up to 10/10 mm² (IEC) or 18-8 AWG (UL/CSA up to 63 A). Installation is simplified with a fast clip device onto a 35 mm DIN rail, supporting any mounting position. Connections are made from top and bottom, with tool-free withdrawal from the busbar possible from the bottom (excluding 125 A models). Dimensions are compact: 85 x 69 x 35 mm (2P) and 85 x 69 x 70 mm (4P). This pedestal ensures efficient wiring and space-saving integration in industrial motor control applications.
- Failsafe bi-directional cylinder-lift terminals at top and bottom
- Cage terminals for currents exceeding 63 A
- Accommodates cables up to 25/25 mm² (IEC) or 18-4 AWG (UL/CSA)
- Fast clip device for 35 mm DIN rail mounting
- Compact dimensions: 85 x 69 x 35 mm (2P) / 85 x 69 x 70 mm (4P)
Specifications
Connection Type | failsafe bi-directional cylinder-lift terminals |
Mounting Type | 35 mm DIN Rail |
Series | R7 |
Size | 85 x 69 x 35 mm (2P) and 85 x 69 x 70 mm (4P) |
