ABB Installation Products UBB 66 Aluminum 2-3/4 inch Service Entrance Compression Splice for Wire Range, End A: 6 ACSR, 6…
UPC: 783786754564
Documents & Media
Contact for Pricing
Minimum Qty: 500
Multiplier: 500
*Contact for lower quantities*
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- 2-3/4 inch service entrance compression splice
- Designed for AL to AL or AL to CU conductor connections
- Accommodates 6 AWG ACSR, 6 AWG Stranded, and 4 AWG Solid Aluminum conductors
- Blue color coding for easy identification
- Requires 5/8 inch die for installation
Specifications
Application | For Standard Comductors |
Color | Blue |
Color | Blue/Blue |
Conductor Range | Side A: #6 ACSR , #6 STR , #4 SOL Side B: #6 ACSR , #6 STR , #4 SOL |
Connection | Compression |
Connection Type | Compression Splice |
Insulation | Insulated |
Material | Aluminum |
Number Of Conductors | 2 |
Series | UBB 66 |
Size | 2-3/4 inch |
Size | 2-25/32 inches long |
Special Features | Prefilled with Oxide Inhibitor and topped with color-coded end caps. Prevents oxidation and keeps out moisture. Solid Center Stops. Easy cable insertion. All splices are marked with installation die codes and compression locations for easy identificaton and installation. Tough Stabilized Nylon Sleeves Resist Installing-tool Pressure and Provide Reliable 600V insulaton |
Standard | ANSI C119.4 |
Type | Compression Splice Service Entrance Insulated |
Package Dimensions (L x W x H) | 16.1 IN x 5.5 IN x 4.3 IN |
Package Dimensions (L x W x H) | 40.894 cm x 13.97 cm x 10.922 cm |
Package Weight (Imperial) | 0.0500 L |
Package Weight (Metric) | 0.0230 kg |
AL300N
2HoleStandard BarrelAluminum Compression Lug 300 MCM -1/2 Bolt Standard BarrelAluminum Compression Lugs is a type ofaluminum compression connector that is produced from high conductivityaluminum tubing.Center stop assures proper cable installation.They are tin-plated to provide corrosion resistance and are marked with die index and color coded for easy reference. Listed for 35KV maximum when properly installed.
ASC 800 TN
Tin-Plated Aluminum Straight Compression Splice for Aluminum and Copper Conductors, 800 kcmil AL9CU UL listed. 400 mm2. Installing Dies 140H, 342, 474, 1, 1/2. Length 4-3/4 inch x 1-21/32 inch Outside Diameter. Oil Stop. Oxide Inhibitor. Light Blue Caps.
X 1 N 1010
Aluminum 5-1/2 inch Service Entrance Compression Splice for Wire Range, End A: 1/0 ACSR, 2/0 Stranded, 1/0 Stranded Compact, Yellow, End B: 1/0 ACSR, 1/0 Stranded, 2/0 Stranded Compact, Yellow, Die: 840. For AL to AL or AL to CU Conductors.UOG 48
Aluminum 2-3/4 inch Service Entrance Compression Splice for Wire Range, End A: 4 ACSR, 3-4 Stranded, 2 Solid, Green, End B: 8 Stranded, 6 Solid, Green, Die: 5/8. For AL to AL or AL to CU Conductors.X 1 N 2010
Aluminum 5-1/2 inch Service Entrance Compression Splice for Wire Range, End A: 2/0 ACSR, 2/0 Stranded, 3/0 Stranded Compact, Yellow, End B: 1/0 ACSR, 1/0 Stranded, 2/0 Stranded Compact, Yellow, Die: 840. For AL to AL or AL to CU Conductors.X 1 N 204
Aluminum 5-1/2 inch Service Entrance Compression Splice for Wire Range, End A: 2/0 ACSR, 2/0 Stranded, 3/0 Stranded Compact, Orange, End B: 4 ACSR, 3-4 Stranded, 2 Solid, Orange, Die: 840. For AL to AL or AL to CU Conductors.Frequently Asked Questions
What is the color coding for the UBB 66 splice?
The UBB 66 splice is color-coded blue for easy identification.
What industry standards does the UBB 66 splice comply with?
When properly installed, UBB 66 splices comply with ANSI C119.4 and are RUS Accepted.
Is the UBB 66 splice prefilled with an oxide inhibitor?
Yes, UBB 66 splices are prefilled with an oxide inhibitor to prevent oxidation and keep out moisture.
What are the maximum and minimum conductor diameters for UBB 66?
The UBB 66 splice accommodates conductors with a maximum diameter of 0.204 inches and a minimum diameter of 0.184 inches.
What is the voltage rating for UBB 66 splices?
UBB 66 splices feature tough stabilized nylon sleeves that provide reliable 600V insulation.
What material is the UBB 66 splice constructed from?
The UBB 66 splice is constructed from aluminum, providing high conductivity.
What material is the UBB 66 splice constructed from?
The UBB 66 splice is constructed from aluminum, providing high conductivity.
What is the color coding for the UBB 66 splice?
The UBB 66 splice is color-coded blue for easy identification.
What industry standards does the UBB 66 splice comply with?
When properly installed, UBB 66 splices comply with ANSI C119.4 and are RUS Accepted.
Is the UBB 66 splice prefilled with an oxide inhibitor?
Yes, UBB 66 splices are prefilled with an oxide inhibitor to prevent oxidation and keep out moisture.
