ABB - Installation Products TSC 22 CE - Tin Plated Copper, Spade Adapter, 6.5 inch long x 2.25 inch wide x .25 inch thick. Has two .562 inch diameter holes on one end and (2) 30 Degree Off-set Slotted Holes on other end.

ABB Installation Products TSC 22 CE Tin Plated Copper, Spade Adapter, 6.5 inch long x 2.25 inch wide x .25 inch thick. Has…

UPC: 783786977932

Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 100

Multiplier: 100

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB TSC 22 CE is a tin-plated copper spade adapter designed for electrical connections. This adapter measures 6.5 inches in length, 2.25 inches in width, and has a thickness of 0.25 inches. It features two 0.562-inch diameter holes on one end, suitable for standard bolt sizes, facilitating secure mounting or connection points. The opposite end is equipped with two 30-degree offset slotted holes, providing flexibility in alignment and connection positioning. The tin plating on the copper material offers enhanced conductivity and corrosion resistance, crucial for reliable electrical performance in various industrial settings. This component is identified by SKU TSC 22 CE and falls under the UNSPSC code 39121443, indicating its classification within electrical equipment and accessories. Key Specifications: - Material: Tin Plated Copper - Dimensions: 6.5" L x 2.25" W x 0.25" T - Hole Configuration (End 1): Two (2) 0.562" diameter holes - Hole Configuration (End 2): Two (2) 30-degree offset slotted holes - Manufacturer: ABB - Installation Products - SKU: TSC 22 CE
  • Constructed from durable tin-plated copper for enhanced conductivity and corrosion resistance.
  • Generous dimensions: 6.5 inches long x 2.25 inches wide x 0.25 inches thick.
  • Features two 0.562-inch diameter holes on one end for secure fastening.
  • Includes two 30-degree offset slotted holes on the opposite end for flexible alignment.
  • ABB Installation Products SKU: TSC 22 CE.

Specifications

Connection
Mechanical
Finish
Tin Plated
Insulation
False
Material
Copper
Size
6.5 inch long x 2.25 inch wide x .25 inch thick
Type
NEMA Transformer Spade Adapter
Width
2.25 in
Width
57.15 mm
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
0.9500 L
Package Weight (Metric)
0.4310 kg
