ABB - Installation Products SSS 4 KNHEC - Storm Safe Pin Terminal Kit, (1) Pin Terminal for 4 ACSR-CPR, Pin 1.43 inch Long, (1) Storm Safe Kit.

ABB Installation Products SSS 4 KNHEC Storm Safe Pin Terminal Kit, (1) Pin Terminal for 4 ACSR-CPR, Pin 1.43 inch Long, (1)…

UPC: 783786053070


Documents & Media
Manufacturer Product Website

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB SSS 4 KNHEC Storm Safe Pin Terminal Kit provides a reliable termination solution for 4 AWG ACSR-CPR conductors in overhead distribution systems. This kit includes one 1.43-inch long pin terminal designed for direct burial or pole-top installations where environmental durability is critical. The terminal is compatible with 4 AWG ACSR-CPR conductors, ensuring secure mechanical and electrical connections in medium-voltage applications up to 35 kV. The Storm Safe design incorporates corrosion-resistant materials and a crimp-style termination that resists vibration and thermal cycling, reducing maintenance requirements in harsh outdoor conditions. Typical applications include utility pole crossarms, transformer connections, and overhead line terminations where exposure to moisture, UV, and temperature fluctuations is common. The kit includes all necessary components for installation, eliminating the need for separate hardware purchases. The 1.43-inch pin length provides adequate clearance for standard insulator configurations while maintaining mechanical integrity under load.
  • Designed for 4 AWG ACSR-CPR conductors in overhead distribution systems
  • 1.43-inch pin length for standard insulator compatibility
  • Storm Safe design resists corrosion, UV, and vibration
  • Includes full installation kit for immediate deployment
  • Compatible with medium-voltage applications up to 35 kV

Specifications

Type
Storm-Safe Pin Kits
Wire Size
#4 ACSR AWG
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
0.3500 L
Package Weight (Metric)
0.1590 kg
