UPC: 034481045632
Contact for Pricing
Overview
- 0.25-inch thick, UV-resistant polycarbonate window
- Heavy-gauge steel or 304 stainless steel frame
- Integral weld studs and compression clips
- Oil-resistant neoprene gasket for watertight seal
- ANSI 61 gray or brushed stainless steel finish
Specifications
Application | Carlon hinged window kits are used to create a NEMA 4X environment on electronic control panels |
Color | ANSI 61 gray |
IP Rating | IP66 |
Material | Polycarbonate |
Material | Polycarbonate, Steel/Stainless Steel |
Material Quality | Polycarbonate |
Nema Rating | Type 12, Type 4 |
Series | NI64W |
Size | 6 inch by 4 inch |
Special Features | High-impact strength |
Standard | cULus, E88685 |
Standard | cULus, E88685 / cULus, E88685 |
Type | Circuit Safe Enclosure Accessories |
Package Dimensions (L x W x H) | 0.01 IN x 0.01 IN x 0.01 IN |
Package Dimensions (L x W x H) | 0.0254 cm x 0.0254 cm x 0.0254 cm |
Package Weight (Imperial) | 1.140 L |
Package Weight (Metric) | 0.517 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
How to Install the NI64W Window Kit
This guide provides step-by-step instructions for installing the NI64W window kit, ensuring a secure and leak-proof fit.
Estimated time: 45m
Tools needed:
Screwdriver, Drill, File or deburring tool
Supplies needed:
Mounting screws, Seal rings, Cap nuts, RTV sealant (if needed)
- Prepare the mounting surface
Ensure the mounting surface is smooth and flat. If the surface is uneven, apply RTV sealant to create a leak-proof seal.
- Cut and drill the mounting area
Use the provided template to cut out the area for the window. Drill screw locations with a #5 or #6 drill bit (.205" diameter).
- Install the window
Inspect the 'T' shaped mounting surface gasket for damage. Position the window, ensuring the gasket compresses 50% of its height, and secure it with mounting screws. Tighten screws to 10 in-lb of torque after placing seal rings and cap nuts.
