ABB - Installation Products LRTR 4 - Aluminum Quick Disconnect Transformer Connectors - LRTR Series, wire size 12-350, length 7, stud size 5/8, outlets 4

ABB Installation Products LRTR 4 Aluminum Quick Disconnect Transformer Connectors - LRTR Series, wire size 12-350, length…

UPC: 783786738106

Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 50

Multiplier: 50

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB LRTR 4 is a robust aluminum quick disconnect transformer connector designed for reliable electrical connections in industrial settings. Manufactured by ABB - Installation Products, this connector, SKU LRTR 4, is part of the LRTR Series, specifically engineered for efficient and secure transformer terminations. It accommodates wire sizes ranging from 12 AWG to 350 kcmil, offering significant flexibility for various conductor gauges. The connector features a 7-inch length and a 5/8-inch stud size, ensuring substantial contact area and secure mounting capabilities. With four distinct outlets, the LRTR 4 facilitates the connection of multiple conductors to a single transformer terminal, streamlining wiring configurations and reducing installation complexity. The quick disconnect design allows for rapid and tool-free separation and reconnection of circuits, which is invaluable for maintenance, troubleshooting, or system modifications. Constructed from durable aluminum, this connector provides excellent conductivity and resistance to corrosion, crucial for long-term performance in demanding electrical environments. Its 4-pole configuration makes it suitable for multi-phase transformer applications where simultaneous connection to several phases is required. The UNSPSC code for this product is 39121443, categorizing it within electrical connectors. Ideal for power distribution, industrial machinery, and electrical infrastructure projects, the ABB LRTR 4 ensures dependable power flow and efficient electrical system management. Its straightforward design and high-quality materials contribute to reduced downtime and enhanced operational safety.
  • ABB LRTR 4 Aluminum Quick Disconnect Transformer Connector
  • 4-Pole Configuration for multi-phase applications
  • Accommodates wire sizes from 12 AWG to 350 kcmil
  • 7-inch length with a 5/8-inch stud size
  • Durable aluminum construction for conductivity and corrosion resistance

Specifications

Application
Stud Mount Transformer Connector
Conductor Range
#12 to 350 kcmil
Connection
Mechanical
Insulation
EPDM Rubber Coating
Material
Aluminum Connector, EPDM Rubber coating
Number of Conductors
4
Size
7 inches
Special Features
Left Hand or Right Hand Installation Capability. Disconnectable - easy to install or remove and fully insulated with EPDM Rubber. Dual Rated to accept Aluminum or Copper Conductors
Type
Quick-Disconnect Transformer Connector
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
1.0500 L
Package Weight (Metric)
0.4760 kg
