ABB Installation Products L 300-38 Copper Tin-Plated One-Hole Lugs, wire size 300 kcmil CU, Installing Dies 781, 17, 66.…
UPC: 783786739004
Documents & Media
Contact for Pricing
Minimum Qty: 100
Multiplier: 100
*Contact for lower quantities*
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- Tin-plated copper construction for corrosion resistance
- Designed for 300 kcmil copper wire
- CSA and UL listed for safety and reliability
- 1-1/4 inch pad width and 2.000 inch barrel length
- Compatible with installing dies 781, 17, and 66
Specifications
Application | General Applications |
Connection | Compression |
Finish | Tinned |
Housing Material | Copper |
Insulation | None |
Size | Overall Length 3.796 inches, Pad Width 1.224 inches, Pad Length 1.109 inch, Hole Diameter .406 inch. Pad Thickness .153 inch |
Special Features | Tin-Plated to resist corrosion. Produced from seamless electrolytic copper tubing which provides high conductivity and minimizes voltage drop. Marked with a catalog number, conductor sizes and die references |
Standard | UL E9809. CSA LR35518 |
Type | Compression Lug One Hole |
Wire Size | 300 kcmil |
Package Dimensions (L x W x H) | 0.01 IN x 0.01 IN x 0.01 IN |
Package Dimensions (L x W x H) | 0.0254 cm x 0.0254 cm x 0.0254 cm |
Package Weight (Imperial) | 0.2200 L |
Package Weight (Metric) | 0.1000 kg |

L 300-58
Copper Tin-Plated One-Hole Lugs, wire size 300 kcmil CU, Installing Dies 781, 17, 66. Overall Length 3-51/64 inches, Pad Width 1-1/4 inches, Pad Length 1-7/64 inch, Hole Diameter 11/16 inch. Pad Thickness 5/32 inch. Barrel Length 1-15/16 inch. CSA. UL listed.
SPM-24L
Service Post Connector - Two Wire Type 4 STR Service Post Connectors is used for connecting one or two conductors. Made from high copper content hard-drawn rod. Lay-in feature makes them excellent for continuous loop grounding and bonding. Used to ground to bar or plate. Suitable for direct burial in earth or concrete.
E-6HPS-25
Type HPS Plated Split-Bolt Connector with Spacer made of Copper Alloy for Use on Copper, Aluminum, ACSR Conductors. Conductor Range for Equal Main and Tap 6 Sol.-12 Sol.Frequently Asked Questions
What wire size is the ABB L 300-38 lug designed for?
The ABB L 300-38 lug is designed for 300 kcmil copper wire.
What are the pad dimensions of the L 300-38 lug?
The pad width is 1-1/4 inches and the pad length is 1-7/64 inches.
What is the barrel length of the ABB L 300-38 lug?
The barrel length of the ABB L 300-38 lug is 2.000 inches.
What installing dies are compatible with the L 300-38 lug?
The L 300-38 lug is compatible with installing dies 781, 17, and 66.
Is the ABB L 300-38 lug CSA and UL listed?
Yes, the ABB L 300-38 lug is both CSA and UL listed.
What is the hole diameter on the ABB L 300-38 lug?
The hole diameter on the ABB L 300-38 lug is 13/32 inch.
