ABB - Installation Products KL47-1 - Aluminum 3-1/2 Inch Service Entrance Compression Splice for Wire Range - End A: 2/0 ASCR, 2/0 Str., 3/0 Str. Compact, Gray, End B: 1/0 ASCR, 2/0 Str., 3/0 Str. Compact, Gray, Die: 840. For AL to AL and AL to CU Conductors.

ABB Installation Products KL47-1 Aluminum 3-1/2 Inch Service Entrance Compression Splice for Wire Range - End A: 2/0…

UPC: 783786050390

Documents & Media
Specification SheetManufacturer Product Website

Contact for Pricing

Minimum Qty: 250

Multiplier: 250

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB Installation Products KL47-1 is a 3-1/2 inch aluminum service entrance compression splice designed for reliable electrical connections in utility and industrial installations. This splice accommodates aluminum-to-aluminum (AL to AL) and aluminum-to-copper (AL to CU) conductor applications, ensuring versatility for heavy-duty service requirements. End A supports 2/0 ASCR, 2/0 Stranded, and 3/0 Stranded Compact conductors with a diameter range of 0.448 to 0.414 inches. End B is engineered for 1/0 ASCR, 2/0 Stranded, and 3/0 Stranded Compact conductors within a diameter range of 0.398 to 0.368 inches. The gray color-coded sleeve provides quick identification during installation and maintenance. Constructed from high-conductivity aluminum, the KL47-1 features a solid center barrier and large chamfers for effortless cable insertion. The stabilized-nylon sleeve resists tool pressure and delivers reliable 600V insulation, while the prefilled oxide inhibitor prevents oxidation and moisture ingress. The center stop ensures proper conductor positioning, eliminating guesswork during installation. This splice complies with ANSI C119.4 standards when installed correctly on AL to AL or AL to CU conductors. It is compatible with popular mechanical and hydraulic crimping tools, making it a cost-effective solution for reducing conductor sizes in commercial service applications. The 840 die series ensures consistent, secure crimps for long-term performance in demanding environments. Ideal for overhead service entrances, the KL47-1 is a low-cost alternative to traditional reducing sleeves, offering durability and ease of use in high-current applications. Its compact design and color-coded markings simplify inventory management and field installation.
  • 3-1/2 inch length for heavy-duty service entrance applications
  • Supports 2/0-3/0 AWG AL/CU conductors (End A: 2/0 ASCR, 2/0 Str., 3/0 Str. Compact; End B: 1/0 ASCR, 2/0 Str., 3/0 Str. Compact)
  • Gray color-coded sleeve for quick identification and installation
  • Solid center barrier and large chamfers for easy cable insertion
  • Prefilled with oxide inhibitor to prevent oxidation and moisture ingress

Specifications

Application
For Combinations of Aluminum-to-Aluminum and Aluminum-to-Copper Conductors
Color
Gray
Conductor Range
End A: 2/0 ACSR , 2/0 STR , 3/0 COMPT. End B: 2/0 ACSR , 2/0 STR , 3/0 COMPT
Connection
Compression
Connection Type
Compression Splice
Environmental Conditions
All Seasons / Conditions
Insulation
None
Material
Aluminum
Mounting
None
Number Of Conductors
2
Series
KL
Size
3-1/2 Inch
Special Features
Splices large conductors required for commercial service, use as low cost reducing sleeve. All sizes can be installed with popular mechanical and hydraulic tools. Center stop assures proper conductor positioning. Quick identifications with color-coded foil caps
Standard
Passes the requirements of ANSI C119.4 / Passes the requirements of ANSI C119.4
Type
Compression Splice Service Entrance
Package Dimensions (L x W x H)
6.75 IN x 5.25 IN x 3.7 IN
Package Dimensions (L x W x H)
17.145 cm x 13.335 cm x 9.398 cm
Package Weight (Imperial)
0.1800 L
Package Weight (Metric)
0.0820 kg
Dual Rated Aluminum Splice 6 AWG Dual Rated Aluminum Splices are a type of aluminum compression connector that is produced from high conductivity aluminum tubing. Center stop assures proper cable installation. Electro-tin plated for corrosion resistance. Color coded and marked with die index information. Pre-filled with oxide inhibitor and capped with color coded cap.

ASC6T

Dual Rated Aluminum Splice 6 AWG Dual Rated Aluminum Splices are a type of aluminum compression connector that is produced from high conductivity aluminum tubing. Center stop assures proper cable installation. Electro-tin plated for corrosion resistance. Color coded and marked with die index information. Pre-filled with oxide inhibitor and capped with color coded cap.
Aluminum Reducing Splice Connector for Copper Wire Size 8, Aluminum Wire Size 6, Tin Plated, Die Code 29, Die Color Code Gray

60910

Aluminum Reducing Splice Connector for Copper Wire Size 8, Aluminum Wire Size 6, Tin Plated, Die Code 29, Die Color Code Gray
Aluminum Compression Splice, Tin-Plated to inhibit corrosion, high conductivity thick wall aluminum, Factory pre-filled joint compound and sealed with easy pull-out end plug to inhibit corrosion, Panduit and specified competitor die index numbers marked on barrel for proper crimp die selection, Internal solid stop prevents over-insertion of conductor, UL Listed and CSA Certified to 35 KV and temperature rated to 90C when crimped with Panduit and specified competitor crimping tools and dies.

SA6-T

Aluminum Compression Splice, Tin-Plated to inhibit corrosion, high conductivity thick wall aluminum, Factory pre-filled joint compound and sealed with easy pull-out end plug to inhibit corrosion, Panduit and specified competitor die index numbers marked on barrel for proper crimp die selection, Internal solid stop prevents over-insertion of conductor, UL Listed and CSA Certified to 35 KV and temperature rated to 90C when crimped with Panduit and specified competitor crimping tools and dies.
Aluminum 3-1/2 Inch Service Entrance Compression Splice for Wire Range - End A: 3/0 ASCR, 4/0 Str. Compact, Orange, End B: 4 ASCR, 3-4 Str., 2 Sol., Orange, Die: 840. For AL to AL and AL to CU Conductors.

KL54-1

Aluminum 3-1/2 Inch Service Entrance Compression Splice for Wire Range - End A: 3/0 ASCR, 4/0 Str. Compact, Orange, End B: 4 ASCR, 3-4 Str., 2 Sol., Orange, Die: 840. For AL to AL and AL to CU Conductors.
Compression Service Sleeve, Contax filled, Conductor Range Main 3/0 STR, 4/0 Comp, 4/0 Sol, TAP 3/0 STR, 4/0 COMP, 4/0 SOL, Color Main - Gray, TAP - Gray, Dies 840, W - K840, U249.. For AL to AL and AL to CU Conductors.

KL476-1

Compression Service Sleeve, Contax filled, Conductor Range Main 3/0 STR, 4/0 Comp, 4/0 Sol, TAP 3/0 STR, 4/0 COMP, 4/0 SOL, Color Main - Gray, TAP - Gray, Dies 840, W - K840, U249.. For AL to AL and AL to CU Conductors.
Aluminum 3-1/2 Inch Service Entrance Compression Splice for Wire Range - End A: 3/0 ASCR, 4/0 Str. Compact, Red, End B: 2 ASCR, 1-2 Str., 1 Str. Compact, Red, Die: 840. For AL to AL and AL to CU Conductors.

KL55-1

Aluminum 3-1/2 Inch Service Entrance Compression Splice for Wire Range - End A: 3/0 ASCR, 4/0 Str. Compact, Red, End B: 2 ASCR, 1-2 Str., 1 Str. Compact, Red, Die: 840. For AL to AL and AL to CU Conductors.
Aluminum 3-1/2 Inch Service Entrance Compression Splice for Wire Range - End A: 3/0 ASCR, 4/0 Str. Compact, Yellow, End B: 1/0 ASCR, 1/0 Str., 2/0 Str. Compact, Yellow, Die: 840. For AL to AL and AL to CU Conductors.

KL56-1

Aluminum 3-1/2 Inch Service Entrance Compression Splice for Wire Range - End A: 3/0 ASCR, 4/0 Str. Compact, Yellow, End B: 1/0 ASCR, 1/0 Str., 2/0 Str. Compact, Yellow, Die: 840. For AL to AL and AL to CU Conductors.
Aluminum 3-1/2 Inch Service Entrance Compression Splice for Wire Range - End A: 3/0 ASCR, 4/0 Str. Compact, Gray, End B: 2/0 ASCR, 2/0 Str., 3/0 Str. Compact, Gray, Die: 840. For AL to AL and AL to CU Conductors.

KL57-1

Aluminum 3-1/2 Inch Service Entrance Compression Splice for Wire Range - End A: 3/0 ASCR, 4/0 Str. Compact, Gray, End B: 2/0 ASCR, 2/0 Str., 3/0 Str. Compact, Gray, Die: 840. For AL to AL and AL to CU Conductors.

Frequently Asked Questions

How are KL47-1 connectors quickly identified?

KL47-1 connectors feature quick identification through color-coded foil caps.

How does the KL47-1 ensure proper conductor positioning?

The KL47-1 connector features a center stop that assures proper conductor positioning during installation.

What standards does the KL47-1 connector meet?

The KL47-1 connector passes the requirements of ANSI C119.4.

What is the color code for the KL47-1 connector?

The KL47-1 connector is identified by a Gray color code.

What is the conductor diameter range for KL47-1?

The conductor diameter range for KL47-1 is a maximum of .448 in and a minimum of .414 in.

What conductor types is KL47-1 compatible with?

The KL47-1 connector is compatible with 2/0 ACSR, 2/0 stranded, and 3/0 stranded compact conductors. It is designed for aluminum-aluminum and aluminum-copper conductors.

What conductor types is KL47-1 compatible with?

The KL47-1 connector is compatible with 2/0 ACSR, 2/0 stranded, and 3/0 stranded compact conductors. It is designed for aluminum-aluminum and aluminum-copper conductors.

What is the conductor diameter range for KL47-1?

The conductor diameter range for KL47-1 is a maximum of .448 in and a minimum of .414 in.

What is the color code for the KL47-1 connector?

The KL47-1 connector is identified by a Gray color code.

What standards does the KL47-1 connector meet?

The KL47-1 connector passes the requirements of ANSI C119.4.
