UPC: 786210813905
Documents & Media
Contact for Pricing
Minimum Qty: 1000
Multiplier: 1000
*Contact for lower quantities*
Overview
- Two-piece outer sleeve connector for hexagonal range
- Length: 1/4 Inch / 6.4mm
- Inner Diameter: .232 Inches / 5.90mm
- Outer Diameter: .263 Inches / 6.70mm
- Soft bronze construction with tin plating, color: Orange
Specifications
Color | Orange |
Material | Soft Bronze |
Special Features | Shielded cable grounding system made of 2 cylindrical sleeves (inner sleeve + outer sleeve), for solderless crimp connection. Outer sleeve for the Hexagonal Range (the outer sleeve is crimped with a hand tool and the result is a hexagonal-shaped crimp), for grounding shielded and coaxial cables. The sleeves are color coded according to their size. Millions of installations in communications, aerospace, electronic, telephone, radio and TV applications |
Type | Two-Piece Outer Sleeve Connector |
Package Dimensions (L x W x H) | 3.5 IN x 3 IN x 3 IN |
Package Dimensions (L x W x H) | 8.89 cm x 7.62 cm x 7.62 cm |
Package Weight (Imperial) | 0.0010 L |
Package Weight (Metric) | 0.0010 kg |
GSB205NP
Two Piece Inner Sleeve Connector for Hexagonal Range, Length 5/16 Inch/7.9mm, Inner Diameter .205 Inches/5.20mm, Outer Diameter .245 Inches/6.22mm, Color Orange, Hard Bronze, Nickel Plated
GSC219NP
Two Piece Outer Sleeve Connector for Hexagonal Range, Length 1/4 Inch/6.4mm, Inner Diameter .219 Inches/5.56mm, Outer Diameter .250 Inches/6.35mm, Color Green, Soft Bronze, Nickel Plated
GSC590
Two Piece Outer Sleeve Connector for Round Range, Length 15.2mm, Inner Diameter 14.99mm, Outer Diameter 17.02mm, Color Red, Copper Alloy
2704
Liquidtight Cord Connector, 1-1/4 Inch, Straight, Cord Range 1.270 to 1.470 Inch, Meets Coast Guard CG293, Nylon, Black
2922AL
Liquidtight Strain Relief Connector, 1/2 Inch, Straight, Cord Range 0.500 to 0.750 Inch, Throat Diameter 9/16 Inch, Aluminum Body, Glandnut, and Grip, Rubber Bushing
2941
Liquidtight Strain Relief Connector, 1 Inch, Straight, Cord Range 0.500 to 0.750 Inch, Throat Diamter 11/16 Inch, Steel Body, Glandnut, and Grip, Rubber BushingFrequently Asked Questions
Are GSC232 parts free of burrs?
Yes, all parts are free of burrs and sharp edges.
How to order a nickel-plated GSC232 connector?
To order a nickel-plated version, add the "NP" suffix to the catalog number, for example, GSC232NP.
Is GSC232 compatible with WT540 dies?
The GSC232 connector is not compatible with WT540 dies.
What dies are used with GSC232 and WT440?
For use with the WT440 tool, the GSC232 connector requires 4410 interchangeable dies.
Which hand tool is compatible with GSC232?
The GSC232 connector is compatible with the WT410 hand tool.
What is the color code for GSC232?
The GSC232 connector is identified by the color code ORANGE.
What are the dimensions of the GSC232 connector?
The GSC232 connector has an I.D. of 0.232 inches and an O.D. of 0.263 inches.
Which hand tool is compatible with GSC232?
The GSC232 connector is compatible with the WT410 hand tool.
Are GSC232 parts free of burrs?
Yes, all parts are free of burrs and sharp edges.
How to order a nickel-plated GSC232 connector?
To order a nickel-plated version, add the "NP" suffix to the catalog number, for example, GSC232NP.
