ABB - Installation Products FXL 33-175 - Aluminum Flood Seal Connector with EPDM Rubber Coating on main body, 12-1/4 inch High x 2-1/4 inch thick x 10-1/2 inch Long. Total Outlets 6, 3 on each side.

ABB Installation Products FXL 33-175 Aluminum Flood Seal Connector with EPDM Rubber Coating on main body, 12-1/4 inch High x…

UPC: 783786727445


Documents & Media
Manufacturer Product Website

Contact for Pricing

Minimum Qty: 3

Multiplier: 3

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB FXL 33-175 Aluminum Flood Seal Connector is a robust, industrial-grade solution designed for secure cable termination in harsh environments. This connector features a durable aluminum body with an EPDM rubber coating, providing excellent resistance to moisture, corrosion, and mechanical stress. With a total of 6 outlets—3 on each side—the FXL 33-175 supports efficient cable management and distribution in medium to high-voltage applications. Its dimensions of 12.25 inches in height, 2.25 inches in thickness, and 10.5 inches in length make it suitable for compact installations where space is a constraint. The EPDM coating ensures long-term reliability by preventing water ingress and protecting against environmental contaminants. Ideal for use in power distribution panels, control cabinets, and outdoor enclosures, this connector meets the demands of industrial, utility, and commercial installations requiring reliable and weatherproof cable connections.
  • Aluminum body with EPDM rubber coating for corrosion and moisture resistance
  • 6 total outlets (3 on each side) for efficient cable distribution
  • Compact dimensions: 12.25 in (H) x 2.25 in (T) x 10.5 in (L)
  • Suitable for medium to high-voltage industrial applications

Specifications

Application
High Conductivity Aluminum Connector
Color
Black
Conductor Range
up to 1000 kcmil
Connection
Mechanical
Insulation
EPDM Rubber
Material
Aluminum Connector, EPDM Rubber Insulation
Material
Aluminum with EPDM Rubber Coating
Number of Conductors
6
Poles
6 (3 on each side)
Series
FXL
Size
10-1/2 inch long
Size
12-1/4 inch High x 2-1/4 inch Thick x 10-1/2 inch Long
Special Features
Rubber Insulation Ensures a Watertight Connection. Outlets Equipped with 1/2-13 UNC Hex-Head Screws with Captive Belleville Washers to Accept Two-Hole NEMA Aluminum or Copper Compression Lugs. All Connectors are 100 Percent Hi-Pot tested at 4000 Volts for 60 seconds
Type
Flood Seal Bus Connector 175 Series
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
8.5100 L
Package Weight (Metric)
3.8600 kg
Aluminum Flood Seal Connector with EPDM Rubber Coating on main body, 12-1/4 inch High x 2-1/4 inch thick x 6-3/4 inch Long. Total Outlets 4, 2 on each side.

FXL 22-175

Aluminum Flood Seal Connector with EPDM Rubber Coating on main body, 12-1/4 inch High x 2-1/4 inch thick x 6-3/4 inch Long. Total Outlets 4, 2 on each side.
Aluminum Flood Seal 125 Series Screw-on Transformer Connectors, length 4-7/8 inch, stud size 5/8 inch, height 3-7/8 inch, outlets 2

FTU 125-2

Aluminum Flood Seal 125 Series Screw-on Transformer Connectors, length 4-7/8 inch, stud size 5/8 inch, height 3-7/8 inch, outlets 2
Aluminum Universal Quick Disconnect Transformer Connectors - LRT-UW Series, fully insulated, cable range 12-350, length 4 in, height 2-1/2 in, stud size 5/8 & 1, outlets 8

LRT 44 UW

Aluminum Universal Quick Disconnect Transformer Connectors - LRT-UW Series, fully insulated, cable range 12-350, length 4 in, height 2-1/2 in, stud size 5/8 & 1, outlets 8
Aluminum Flood Seal Connector with EPDM Rubber Coating on main body, 12-1/4 inch High x 2-1/4 inch thick x 14-1/4 inch Long. Total Outlets 8, 4 on each side.

FXL 44-175

Aluminum Flood Seal Connector with EPDM Rubber Coating on main body, 12-1/4 inch High x 2-1/4 inch thick x 14-1/4 inch Long. Total Outlets 8, 4 on each side.
Copper NEMA Lug Tees Taps for Cable Buses, Main 1000, 1-1/2 inch x 3 inch x 1-1/2 inch. Bolt Holes Spaced on 1-3/4 inch Centers. Includes Hardware - (2) Stainless Steel 1/2-13 x 3 inch Full Thread Bolts, (2) Stainless Steel 1/2 inch Lock Washers and (2) Stainless Steel 1/2 inch Nuts.

NLTT 1000

Copper NEMA Lug Tees Taps for Cable Buses, Main 1000, 1-1/2 inch x 3 inch x 1-1/2 inch. Bolt Holes Spaced on 1-3/4 inch Centers. Includes Hardware - (2) Stainless Steel 1/2-13 x 3 inch Full Thread Bolts, (2) Stainless Steel 1/2 inch Lock Washers and (2) Stainless Steel 1/2 inch Nuts.
Aluminum Universal Quick Disconnect Transformer Connectors - RAU Series, cable range 6-500, insulator length 5-1/2 in, outlets 4

RAU 4500

Aluminum Universal Quick Disconnect Transformer Connectors - RAU Series, cable range 6-500, insulator length 5-1/2 in, outlets 4
Aluminum Universal Quick Disconnect Transformer Connectors - RAU Series, cable range 6-500, insulator length 8-7/8 in, outlets 8

RAU 8500

Aluminum Universal Quick Disconnect Transformer Connectors - RAU Series, cable range 6-500, insulator length 8-7/8 in, outlets 8
Aluminum Flood-Seal Multi-Port Connectors - RMX Series, Cable entry from either side, length 10-7/8 inch, outlets 6

RXM 33

Aluminum Flood-Seal Multi-Port Connectors - RMX Series, Cable entry from either side, length 10-7/8 inch, outlets 6

Frequently Asked Questions

What are the dimensions of the FXL 33-175?

The FXL 33-175 measures 12.25 inches in height, 2.25 inches in thickness, and 10.5 inches in length.

How many outlets does the FXL 33-175 have?

The FXL 33-175 has a total of 6 outlets, with 3 outlets on each side.

What is the material of the FXL 33-175?

The main body is made of aluminum with an EPDM rubber coating for protection.

Is the FXL 33-175 suitable for outdoor use?

Yes, the EPDM rubber coating provides resistance to moisture and environmental contaminants, making it suitable for outdoor applications.
