ABB - Installation Products FTN 175-55-6 NLCUTN - Tin Plated Copper Transformer Spade Connector, 6 hole NEMA Pad - .75 inch thick x 4 inch wide on top angled to 8 inch wide on bottom of pad x 6.625 inch Tall - Welded to Two Rows of 5 Towers. 11.75 inch wide. Gray PVC Coating. Includes 20 Screws.

ABB Installation Products FTN 175-55-6 NLCUTN Tin Plated Copper Transformer Spade Connector, 6 hole NEMA Pad - .75 inch thick x 4 inch…

UPC: 075114204088


Documents & Media
Manufacturer Product Website

Contact for Pricing

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

This ABB Tin Plated Copper Transformer Spade Connector (SKU: FTN 175-55-6 NLCUTN) is engineered for robust electrical connections in transformer applications. It features a substantial 6-hole NEMA pad, measuring .75 inches thick and 4 inches wide at the top, angling to 8 inches wide at the bottom of the pad. The overall height of the pad is 6.625 inches. This connector is welded to two rows of 5 towers, providing ample termination points. The total width of the unit is 11.75 inches. A durable gray PVC coating offers insulation and protection. The connector includes 20 screws for secure installation. Designed for reliable performance in electrical infrastructure, this component facilitates secure and efficient power distribution. Its substantial construction and multiple connection points make it suitable for demanding electrical assemblies where dependable conductivity and mechanical integrity are paramount. The tin plating on the copper ensures excellent conductivity and corrosion resistance, crucial for long-term operational stability in transformer installations. This product falls under UNSPSC code 39121443.
  • Tin Plated Copper construction for conductivity and corrosion resistance
  • 6-hole NEMA pad with dimensions: 0.75" thick, 4"-8" wide, 6.625" tall
  • Welded to two rows of 5 towers for multiple termination points
  • Overall width of 11.75 inches
  • Durable gray PVC coating for insulation and protection, includes 20 screws

Specifications

Color
Gray
Conductor Range
4/0 to 1000 kcmil
Connection
Mechanical
Connection Type
Screw
Finish
Tin Plated
Insulation
True
Material
Copper
Material
Copper with Tin Plating
Nema Rating
6 hole NEMA Pad
Series
FTN 175-55-6 NLCUTN
Size
11-3/4 inch
Size
.75 inch thick x 4 inch wide on top angled to 8 inch wide on bottom of pad x 6.625 inch Tall
Standard
Meets or Exceeds ANSI C119.4 Specifications
Type
Transformer Spade Connector
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
45.0000 L
Package Weight (Metric)
20.4120 kg
