ABB - Installation Products FS12-TB - 1/2 Inch Shallow 2 Gang Cast Device Box, Gray Iron Zinc Plated, Dead End, Suitable for Wet Locations When Used with Gasketed Covers

ABB Installation Products FS12-TB 1/2 Inch Shallow 2 Gang Cast Device Box, Gray Iron Zinc Plated, Dead End, Suitable for…

UPC: 786210197128

Documents & Media
Specification SheetManufacturer Product Website

Contact for Pricing

Minimum Qty: 5

Multiplier: 5

*Contact for lower quantities*

Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.

Overview

The ABB FS12-TB is a 1/2-inch shallow 2-gang cast device box engineered for reliable electrical installations in demanding environments. Constructed from durable Class 30 gray iron alloy, this device box delivers exceptional strength and corrosion resistance with a zinc-plated finish and aluminum acrylic paint coating. Its dead-end configuration is specifically designed for terminating conduit runs, providing a secure and organized connection point for electrical wiring. The FS12-TB is rated for wet locations when used with a gasketed cover, making it ideal for outdoor, industrial, or exposed applications where moisture resistance is critical. With dimensions of 2.00" (A) x 4.63" (B) x 4.28" (C) and a throat diameter range of 0.570" to 0.610", this box offers a compact yet spacious housing for electrical devices. Suitable for use in commercial, industrial, and residential settings, the FS12-TB provides a dependable solution for electrical installations requiring robust protection and long-term reliability. Its construction and materials meet the demands of harsh environments, ensuring operational integrity and safety.
  • 1/2-inch shallow 2-gang cast device box for conduit termination
  • Class 30 gray iron alloy construction with zinc plating and aluminum acrylic paint
  • Dead-end hub configuration for secure conduit run termination
  • Rated for wet locations when used with a gasketed cover
  • Dimensions: 2.00" (A) x 4.63" (B) x 4.28" (C); throat diameter 0.570"–0.610"

Specifications

Application
Industrial Grade Device Boxes and Raintight Covers Protect Wiring Devices, Switches, Electronic Components, and Terminal Blocks In Dry, Damp and Wet Locations
Color
Gray
Ip Rating
IP66/IP67
Material
Iron
Material
Cast Iron, Zinc Plated
Material
Gray Iron, Zinc Plated
Series
FS
Size
1/2 Inch
Size
1/2 Inch Shallow 2 Gang
Special Features
All Hubs Have NPT Threads with a Minimum of Five Full Threads and Integral Bushing. Internal Grounding Screw Standard on Boxes
Standard
UL E2969
Type
2 Gang, Shallow Device Box, Dead End
Package Dimensions (L x W x H)
4.6 IN x 2 IN x 5.9 IN
Package Dimensions (L x W x H)
11.684 cm x 5.08 cm x 14.986 cm
Package Weight (Imperial)
3.2000 L
Package Weight (Metric)
1.4520 kg
