ABB - Installation Products FS 33-48 - Aluminum Flood-Seal 125 Series Connectors - two-way configuration, one-bolt design, length 5-1/4 inch, outlets 6, 1-Hole per Tower, Includes 6 Insulating Rockets and 6 Screws.
ABB - Installation Products

FS 33-48

UPC: 783786725939

Documents & Media
Manufacturer Product Website

Contact for Pricing

Overview

The ABB Installation Products FS 33-48 is a two-way, one-bolt Aluminum Flood-Seal 125 Series connector designed for reliable electrical connections. This connector measures 5-1/4 inches in length and features six individual outlets, each with a single mounting hole per tower. The package includes six insulating rockets and six screws, ensuring a complete and secure installation. The Flood-Seal design provides protection against environmental ingress, making it suitable for various industrial and outdoor applications where connection integrity is paramount. Its aluminum construction offers good conductivity and corrosion resistance. The single-bolt configuration simplifies installation and maintenance, reducing labor time and potential for error. This connector is part of the 125 Series, indicating its capacity and intended use within specific electrical systems. The inclusion of insulating rockets and screws means the product is ready for immediate deployment upon receipt, minimizing project delays. Focusing on functional design and essential components, the FS 33-48 delivers a straightforward and effective solution for multi-point electrical connections.
  • Two-way, one-bolt configuration for efficient connections
  • 5-1/4 inch length with 6 outlets
  • 1-Hole per Tower design for secure mounting
  • Includes 6 insulating rockets and 6 screws
  • Aluminum Flood-Seal construction for environmental protection

Specifications

Application
Multi-port Connector
Color
Gray
Conductor Range
#12 to 500 kcmil
Connection
Mechanical
Insulation
PVC
Material
Aluminum
Number of Conductors
6
Size
5-1/4 inch
Special Features
6 Towers
Standard
Comply with ANSI C119.4
Type
Flood Seal Multi Port Connector 175 Series - Two-Way Configuration
Package Dimensions (L x W x H)
0.01 IN x 0.01 IN x 0.01 IN
Package Dimensions (L x W x H)
0.0254 cm x 0.0254 cm x 0.0254 cm
Package Weight (Imperial)
1.0000 L
Package Weight (Metric)
0.4540 kg
