Overview
- Max voltage rating: 35kV
- Wire size compatibility: 600 kcmil
- Bolt hole size: 1/2 inch
- Material: Aluminum with tin plating
- Die color code: Black for identification
Specifications
Color | Black |
Material | Aluminum |
Number Of Holes | 2 |
Special Features | Aluminum Lug |
Standard | UL E9809 |
Stud Size | 1/2 in |
Type | Aluminum Two-Hole Lug |
Voltage Rating | 35 kV |
Package Dimensions (L x W x H) | 8 IN x 5 IN x 4 IN |
Package Dimensions (L x W x H) | 20.32 cm x 12.7 cm x 10.16 cm |
Package Weight (Imperial) | 0.4000 L |
Package Weight (Metric) | 0.1810 kg |
RDC1/0
Ratchet Drive Crimping Tool APPLICATIONS: Ratchet Drive Crimping Tool is for non-insulated terminals from 6 to 1/0 AWG and insulated terminals from 22 to 8 AWG. Rugged, compact, and lightweight. Requires minimum effort due to ratchet action, ensuring an excellent crimp every time. FEATURES: TYPE: Insulated and Uninsulated ACTION: Ratchet INSULATED USE: Terminals 22 to 8 AWG NON-INSULATED USE: Terminals 6 to 1/0 AWG MANUFACTURER: NSi Industries PART NUMBER: RDC 1/0 UPC: 662381055309
CD6A
U-Type Compression Die - Pink 1/0 AWG Copper - 2 AWG Aluminum U-Shaped Compression Dies are for use with the NSi-12 Compression Tool and Other Tools. See Cross-Reference Chart below.
13682
Die for 12 Ton 13400 or 13642M Hydrualic Tool for Crimping 204210MT Dragon Tooth Terminals, Brown. .301/.289 Gaging
F4-PS-W-NP
Non-Insulated Parallel Splice Connector For Wire Range #4 AWG, Circular Mil Range 33,100-52,600, Length 0.531 Diameter 0.41, Nickel Plated
AS-K1-H6
Power Distribution Block (1) 2/0-14 AWG Primary (6) 4-14 AWG Secondary Power Distribution Blocks are made of high strength, high-conductivity aluminum alloy and are mounted in a high-strength glass-filled polyester base. Each block can stand alone or combine with other blocks to form a multi-block set.
E989NNJ-5-HD
Molded Junction Box, Length 4 Inch x Width 4 Inch x Depth 2 Inch, Material Polycarbonate, Color Gray
1SNK705010R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
1SNK705030R0000
Combine high performance with compact dimensions: - 1000 V AC / DC IEC 600 V UL, - Opt for the best marking visibility thanks to the up-front, flat marker zone, which lets you mark up to eight digits or increase the font size.
Frequently Asked Questions
What is the maximum voltage rating for this lug?
The ATL6002 supports a maximum voltage rating of 35kV.
What wire size does this lug accommodate?
This lug is designed for 600 kcmil wire size.
What is the bolt hole size on this lug?
The ATL6002 features a 1/2-inch bolt hole for secure fastening.
What is the die color code for this lug?
The die color code for the ATL6002 is black for easy identification.
Is this lug suitable for outdoor use?
The tin plating on the lug provides corrosion resistance, making it suitable for outdoor environments.
How to Install Aluminum Compression Lugs and Splices (Type ATL and ASP)
This guide provides step-by-step instructions for the safe and proper installation of Thomas & Betts Type ATL and ASP aluminum compression lugs and splices for stranded, compressed, compact aluminum and copper conductors.
Estimated time: 30m
Tools needed:
Wire strippers, Wire brush (T&B catalog number WWB1 or equivalent), Crimping tool, Appropriate crimping dies
Supplies needed:
Aluminum compression lugs or splices (Type ATL and ASP), Aluminum or copper conductors, Oxide inhibitor (if not pre-applied)
- Ensure Electrical Safety
WARNING: ELECTRICAL HAZARD! Before beginning any work, turn off all power to the electrical circuit to prevent electric shock.
- Verify Connector and Cable Size
Check the wire size marked on the aluminum connector (Type ATL or ASP) to confirm it is the correct size for the actual aluminum or copper cable you intend to use.
- Prepare Cable Conductor
Carefully strip the insulation from the cable, ensuring not to damage the conductor's strands. Then, use a wire brush (e.g., T&B catalog number WWB1) to thoroughly brush the conductor side that will be inserted into the connector.
- Insert Conductor into Connector
Fully insert the prepared conductor into the barrel of the aluminum compression lug or splice.
- Crimp the Connector
Refer to the provided Tool and Die Index. Select the appropriate crimping tool and die combination for your specific cable size. Crimp the connector the number of times indicated in the chart. For splices, make the first crimp just outside the knurl on each side of the center and space subsequent crimps uniformly. For lugs, make the first crimp at the inner end of the barrel and space crimps uniformly along the barrel.
- Clean the Connection
After crimping, wipe off any excess oxide inhibitor that may be present on the connector and conductor.
