ABB - Installation Products 6TON62XSS - Hex-Flex Die for 6-Ton TBM6PCR-LI, TBM62PCR-LI, TBM62CR-LI and TBM6UNICR-LI Tools for 250 kcmil CU, Die Color Yellow, Die Code 62X
More images
ABB - Installation Products

6TON62XSS

UPC: 075114122719

Documents & Media
Manufacturer Product Website

Contact for Pricing

Overview

This ABB Hex-Flex Die, SKU 6TON62XSS, is specifically engineered for use with ABB's 6-ton hydraulic crimping tools, including models TBM6PCR-LI, TBM62PCR-LI, TBM62CR-LI, and TBM6UNICR-LI. Designed for precision and reliability, this die is optimized for crimping 250 kcmil copper (CU) conductors. The die features a distinct yellow color, identifying it as the 62X die code within the 6-ton series. This ensures correct tool and die pairing for consistent, high-quality terminations. The Hex-Flex die system from ABB Installation Products is known for its efficiency in creating secure electrical connections, crucial for maintaining system integrity and preventing failures in demanding industrial applications. Its robust construction is built to withstand the pressures of repeated use, providing a dependable solution for electrical contractors and maintenance professionals. When paired with compatible ABB 6-ton tools, the 6TON62XSS die delivers the performance required for critical power distribution and industrial wiring projects, ensuring safety and operational continuity. The yellow color coding simplifies identification and selection, minimizing the risk of using incorrect tooling and ensuring compliance with established electrical standards. Invest in the accuracy and durability of ABB's Hex-Flex die for your 250 kcmil copper conductor crimping needs.
  • Designed for ABB 6-ton hydraulic crimping tools (TBM6PCR-LI, TBM62PCR-LI, TBM62CR-LI, TBM6UNICR-LI)
  • Optimized for 250 kcmil copper (CU) conductors
  • Features 62X die code with yellow color identification
  • Ensures precise and reliable crimp connections
  • Part of the ABB Installation Products Hex-Flex die system

Specifications

Capacity
6 ton
Color
Yellow
Material
Stainless Steel
Type
Die
Package Dimensions (L x W x H)
1.9 IN x 1.9 IN x 1.6 IN
Package Dimensions (L x W x H)
4.826 cm x 4.826 cm x 4.064 cm
Package Weight (Imperial)
0.1400 L
Package Weight (Metric)
0.0640 kg
Stainless Steel Die for 6-Ton TBM6PCR-LI, TBM62PCR-LI, TBM62CR-LI and TBM6UNICR-LI Tools for 250 kcmil CU, Die Color Yellow, Die Code 62

6TON62SS

Stainless Steel Die for 6-Ton TBM6PCR-LI, TBM62PCR-LI, TBM62CR-LI and TBM6UNICR-LI Tools for 250 kcmil CU, Die Color Yellow, Die Code 62
Die for Stainless Steel Lug with Bolt Hole size 3/8 Inch, Length 2-7/16 Inch, Plain Finish and for One-Hole Stainless Steel Waterseal Lug - Length 2-7/16 Inches, Thickness 3/32 Inches

297-54251

Die for Stainless Steel Lug with Bolt Hole size 3/8 Inch, Length 2-7/16 Inch, Plain Finish and for One-Hole Stainless Steel Waterseal Lug - Length 2-7/16 Inches, Thickness 3/32 Inches
Stainless Steel Hex Die Set for 6-Ton TBM6 Series Tools for #8 AWG - 600 KCMIL, includes Die Codes 21, 24, 29, 33, 37, 42, 45, 50, 54, 60, 62, 66, 71, 76, 80, 87, 94

TBM6HD1SS

Stainless Steel Hex Die Set for 6-Ton TBM6 Series Tools for #8 AWG - 600 KCMIL, includes Die Codes 21, 24, 29, 33, 37, 42, 45, 50, 54, 60, 62, 66, 71, 76, 80, 87, 94
Die for 12-14 Ton Tools for #8 CU, #10 Al, Die Color Red, Die Code 21

15520SS

Die for 12-14 Ton Tools for #8 CU, #10 Al, Die Color Red, Die Code 21
Die for 12-14 Ton Tools for #2 CU, Die Color Brown, Die Code 33

15528SS

Die for 12-14 Ton Tools for #2 CU, Die Color Brown, Die Code 33
Die for 12-14 Ton Tools for 1/0 CU, #2 Al, Die Color Pink, Die Code 42

15508SS

Die for 12-14 Ton Tools for 1/0 CU, #2 Al, Die Color Pink, Die Code 42
Die for 12-14 Ton Tools for 3/0 CU, 1/0 Al, Die Color Orange/Tan, Die Code 50

15530SS

Die for 12-14 Ton Tools for 3/0 CU, 1/0 Al, Die Color Orange/Tan, Die Code 50
Die for 12-14 Ton Tools 3/0 Aluminum, Die Color Ruby, Die Code 60

15532SS

Die for 12-14 Ton Tools 3/0 Aluminum, Die Color Ruby, Die Code 60

Frequently Asked Questions

What conductor size is this ABB die for?

This ABB Hex-Flex Die is designed for 250 kcmil copper (CU) conductors.

Which ABB tools are compatible with this die?

This die is compatible with ABB 6-ton tools: TBM6PCR-LI, TBM62PCR-LI, TBM62CR-LI, and TBM6UNICR-LI.

What is the die code and color for this ABB 6-ton die?

The die code is 62X and the color is yellow.

What type of conductor material does this die crimp?

This die is specifically for copper (CU) conductors.
