ABB - Installation Products 63170 - Aluminum Compression H-Tap: Wire Range Main: 1000-500, Branch 1000-1/0, Length 6 Inches, Die Code KR, Die Color Code Black
ABB - Installation Products

63170

UPC: 786210631707

Documents & Media
Installation InstructionsSpecification SheetManufacturer Product Website

Contact for Pricing

Overview

The ABB H-Tap Aluminum Compression Connector (SKU: 63170) is engineered for robust electrical connections in industrial settings. This 6-inch connector utilizes a compression connection type, ensuring a secure and reliable bond for aluminum conductors. It is designed to accommodate a wide wire range, with the main line supporting 1000-500 AWG and the branch line supporting 1000-1/0 AWG. The black die color code and KR die code facilitate easy identification and compatibility with standard installation tools. Constructed from high-strength aluminum alloy, this connector offers excellent conductivity and resistance to corrosion, ensuring long-term performance in demanding environments. The formable ribs provide an expanded contact area, while fold-in tabs ensure positive interlock during installation. This H-Tap connector is suitable for tapping into continuous main conductors, serving as a wire joint or a two-way splice. It is rated for 600V applications. Key specifications include: - Manufacturer: ABB - Installation Products - SKU: 63170 - Material: Aluminum Alloy - Length: 6 Inches - Connection Type: Compression - Main Wire Range: 1000-500 AWG - Branch Wire Range: 1000-1/0 AWG - Die Code: KR - Die Color Code: Black - Voltage Rating: 600V This connector is ideal for power distribution, industrial machinery, and infrastructure projects where reliable and efficient electrical connections are critical. Its wide wire range capability helps minimize inventory requirements. For tool and die crimping information, consult the manufacturer's specifications.
  • High-strength aluminum alloy construction for conductivity and corrosion resistance.
  • 6-inch length with compression connection for secure aluminum conductor bonding.
  • Wide wire range: 1000-500 AWG (Main), 1000-1/0 AWG (Branch).
  • KR die code and black color code for easy identification and tool compatibility.
  • Rated for 600V applications, suitable for industrial power distribution.

Specifications

Conductor Size
1000-500 kcmil
Material
Aluminum
Special Features
Fillerlok Tab provides positive interlock and extends wire range
Standard
UL E9809
Tap Size
1000 kcmil to 1/0 AWG
Type
H-Tap
Voltage Rating
600 V
Package Dimensions (L x W x H)
4.88 IN x 2.63 IN x 6.4 IN
Package Dimensions (L x W x H)
12.3952 cm x 6.6802 cm x 16.256 cm
Package Weight (Imperial)
1.610 L
Package Weight (Metric)
0.730 kg
Aluminum Compression H-Tap: Wire Range Main: 2/0-2, Branch 8-14, Length 3/4 Inch, Die Code O, Die Color Code Green

63118

Aluminum Compression H-Tap: Wire Range Main: 2/0-2, Branch 8-14, Length 3/4 Inch, Die Code O, Die Color Code Green
Insulation Piercing Connector 750 MCM - 3/0 AWG Insulation piercing connectors are made for use with copper-copper, copper to aluminum and aluminum to aluminum applications. They are safe to use and are completely insulated, no need to strip wire. They can be installed on energized conductors with no contact at any point. No spacer required between connections. Exclusive "turbo spacer" keeps tap side open while main conductor is being tightened. Watertight and corrosion-free.

IPCS7501

Insulation Piercing Connector 750 MCM - 3/0 AWG Insulation piercing connectors are made for use with copper-copper, copper to aluminum and aluminum to aluminum applications. They are safe to use and are completely insulated, no need to strip wire. They can be installed on energized conductors with no contact at any point. No spacer required between connections. Exclusive "turbo spacer" keeps tap side open while main conductor is being tightened. Watertight and corrosion-free.
Aluminum Compression H-Tap: Wire Range Main: 500-4/0, Branch 4/0-2, Side Tap 2-6, Length 2-3/4 Inches, Die Code N, Die Color Code Red

63160

Aluminum Compression H-Tap: Wire Range Main: 500-4/0, Branch 4/0-2, Side Tap 2-6, Length 2-3/4 Inches, Die Code N, Die Color Code Red
Copper C-Tap, 600V, Wire Range-Main: 6-8, Branch 8-12, Length 9/16 Inch, Height 5/8 Inch, Tin Plated, Die Code 29, Die Color Code Gray

54715TP

Copper C-Tap, 600V, Wire Range-Main: 6-8, Branch 8-12, Length 9/16 Inch, Height 5/8 Inch, Tin Plated, Die Code 29, Die Color Code Gray
H-Tap/C-Tap Insulating Cover for C-Taps 54705, 54710, 54715, for H-Taps CHT81410, Rated 600V, 105 degrees C, Gray Polyproplyene

HTCV1

H-Tap/C-Tap Insulating Cover for C-Taps 54705, 54710, 54715, for H-Taps CHT81410, Rated 600V, 105 degrees C, Gray Polyproplyene
H-Tap Insulating Soft Cover for Cable Range 6 - 2/0 AWG for H-Taps 63110, 63125, Rated 600V, 90 degrees C, Material: Polypropylene, Black

HT20C

H-Tap Insulating Soft Cover for Cable Range 6 - 2/0 AWG for H-Taps 63110, 63125, Rated 600V, 90 degrees C, Material: Polypropylene, Black
Copper H-Tap for Wire Range Main: 500-4/0 (350-4/0 Flex), Branch (250-1/0 Flex) 4/0-1/0, Brown N

CHT50010-5

Copper H-Tap for Wire Range Main: 500-4/0 (350-4/0 Flex), Branch (250-1/0 Flex) 4/0-1/0, Brown N
Locktite Bronze, Tee-Parallel Taps, Code Copper Conductor, Main Size 300-500 kcmil, Branch Size 4/0-500 kcmil. Length 3-1/16 inch, Width 1-7/8 inch. Depth 1-5/8 inch.

35013

Locktite Bronze, Tee-Parallel Taps, Code Copper Conductor, Main Size 300-500 kcmil, Branch Size 4/0-500 kcmil. Length 3-1/16 inch, Width 1-7/8 inch. Depth 1-5/8 inch.

How to Install the 63170 Compression Tap

This guide provides step-by-step instructions for installing the 63170 Compression Tap, ensuring safe and effective electrical connections.

Estimated time: 45m

Tools needed:

Screwdriver, Wire strippers, Multimeter

Supplies needed:

Mounting screws, Terminal connectors, ALUMA-SHIELD® Aluminum Joint Compound

  1. Prepare the cables

    Strip the insulation from the cables using a whittling technique. Ensure not to nick the strands to avoid breakage.

  2. Apply joint compound

    For aluminum cables, apply a thin layer of ALUMA-SHIELD® Aluminum Joint Compound to the stripped area and clean the cable with a wire brush or emery cloth.

  3. Insert and crimp the connector

    Center the stripped cable in the Main or Branch grooves of the connector. Close the FILLERLOK™ tab and use the appropriate crimping tool to compress the connector according to the specified number of crimps.

  4. Remove sharp edges

    After crimping, carefully remove any sharp edges, flashes, or burrs created during the crimping process to ensure safety.

  5. Insulate the connection

    Follow the insulation methods specified in the installation table to properly insulate the crimped connections.
