Contact for Pricing
Overview
- Voltage range: 48-110V AC, 24-125V DC
- Current rating: 800A at 690V (IEC AC-1)
- Supports conductor cross-sections: 4mm² to 2x300mm²
- Mounting options: DIN rail or direct
- Part of ABB EH450-800 series
- Suitable for DIN rail or direct mounting
Specifications
Application | Mainly used for controlling 3-phase motors and generally for controlling power circuits up to 690 V AC and 220 V DC. The contactors can also be used for many other applications such as bypass, capacitor switching, lighting, DC power circuits. |
Connection Type | 4mm² to 2x300mm² |
Connection Type | Screw Terminal / 4mm² to 2x300mm² |
Current Rating | 800 A |
Material | Varistor + RC |
Mounting Type | DIN rail mounting or direct installation |
Mounting Type | DIN rail or direct mounting |
Mounting Type | DIN rail / Direct installation |
Series | EH450-800 |
Series | RC-EH |
Size | 4mm² up to 2x300mm² |
Size | 82x110x108mm |
Special Features | Terminal type: Screw terminals |
Standard | RoHs, CSA, cUL, CE, GOST |
Type | Contactors |
Voltage Rating | 48-110V AC / 24-125V DC |
Voltage Rating | 48-110AC/24-125DC |
Package Dimensions (L x W x H) | 5.4 IN x 2.4 IN x 2.8 IN |
Package Dimensions (L x W x H) | 13.716 cm x 6.096 cm x 7.112 cm |
Package Weight (Imperial) | 0.090 L |
Package Weight (Metric) | 0.041 kg |
UTP6AL1MBU
The TX6A™ 10Gig Cat 6A UTP Patch Cord is a 1-Meter, Blue cord constructed of 24 AWG, unshielded, twisted pair stranded, LSZH (60332-1) cable with high-performance modular plugs. Its MaTriX Tape Technology limits alien crosstalk, ensuring 10 Gb/s transmission. The tangle-free latch prevents snags and ensures a fast release, streamlining moves, adds, and changes. Enabled with RapidID, the product has pre-installed barcodes for simple port mapping using RapidID software.
CPP24FMWBLY
The Mini-Com Flush Mount Modular Patch Panel accepts up to 24 Mini-Com Modules for unshielded applications in 1 RU, and mounts to 19 inch and 23 inch racks and cabinets. The panel mounts flush with the rack and can be identified with adhesive labels and is black.
3085
Super-Safeway® Multiple Outlet Box, Extended Depth, 2-Sided, F2 (1/2") Cord Grip Body, with Flip Lids for (2) Duplex Not Included
CUSTOMDIN
DIN rail is a universal mounting option for electrical and industrial control products such as circuit breakers electrical supplies terminal blocks and more. The rail system is used to stabilize a wide variety of devices and products. Ordering pre-cut DIN rail helps increase productivity and decrease jobsite clutter. On-site Flexibility Streamline custom cuts DIN rail to any length so it is ready to use when it arrives on the jobsite. Additionally DIN rail can be easily removed if relocation is necessary. Features of Custom DIN Rail from Streamline - All cut DIN rail from Streamline is galvanized steel made to eliminate rusting. Streamline ensures that all custom DIN rail orders are: De-burred Custom Length Any quantity 1-1000+ Quick turnaround (typically 2 weeks or less from receipt of order) This mechanical support structure is a must for all electrical parts solutions big or small. DIN rail allows for mounting hardware easily and quickly. These durable and versatile rails make the perfect solution for all mounting applications. Save space time and money with these cost-effective mounting solutions. Order your custom cut DIN rail today!
F62ERLNSNSNM002
OM1 2 fiber, 16mm jacket, patchcord, Riser (OFNR) rated, LC duplex to SC duplex, Std IL
CESUM3-C15
Membrane plate cable entry system offers a good strain relief while maintaining IP/NEMA ingress sealing rating. The CESUM3-C15 is a Rectangular Un-Terminated Cable Entry System, 4.1" (103 mm) Long, with 8 Openings 0.12" (3.0 mm) to 0.31" (8 mm), 3 Openings 0.20" (5.1 mm) to 0.35" (9.0 mm), 4 Openings 0.3" (7.5 mm) to 0.47" (12.0 mm). Color is Black. Standard Package Quantity is 1 PC.
Frequently Asked Questions
What voltage ranges does the RC-EH800/110 support?
The device supports AC input voltages from 48V to 110V and DC input voltages from 24V to 125V.
What is the current rating of the RC-EH800/110?
The surge suppressor is rated for IEC AC-1 operational currents up to 800A at 690V.
What conductor cross-sections does the RC-EH800/110 accommodate?
The device supports conductor cross-sections ranging from 4mm² up to 2x300mm².
How can the RC-EH800/110 be mounted?
The surge suppressor can be mounted on a DIN rail or directly to a surface.
What is the maximum operating temperature for the RC-EH800/110?
The device is rated for operation at temperatures up to 40°C.
How to Install the ABB RC-EH800/110 Surge Suppressor
Step-by-step guide to mounting and wiring the ABB RC-EH800/110 surge suppressor.
Estimated time: 15m
Tools needed:
Screwdriver, Wire strippers, Crimping tool
Supplies needed:
Mounting screws, Conductors (4mm² to 2x300mm²), Cable ties
- Prepare the mounting surface
Ensure the mounting surface is clean and flat. For DIN rail mounting, attach the rail securely to the surface.
- Mount the surge suppressor
Position the RC-EH800/110 on the DIN rail or surface. Secure it using the provided mounting screws.
- Connect the conductors
Strip the insulation from the conductors and insert them into the appropriate terminals. Tighten the screws to secure the connections.
- Verify connections
Double-check all connections for tightness and proper alignment. Ensure no loose wires are present.
- Test the installation
Power up the system and verify that the surge suppressor is functioning correctly. Monitor for any signs of overheating or abnormal operation.
