ABB Electrification 51026CF-W WHITE COVER FRAME 8 MODULESSIZE 2X4
Contact for Pricing
Call +1 (262) 252-1600 (toll-free 877-268-3700) or email [email protected] for pricing and availability.
Overview
- White cover frame for 8-module (2x4) panel configurations
- 35mm DIN rail mountable
- Conforms to EN/IEC 60715 standards
- Designed for secure housing of ABB auxiliary contacts and contactors
- Facilitates precise component alignment for motor protection and control
Specifications
Color | White |
Material | Plastic |
Material | Plastic/Composite |
Material | Metal (35mm rail) |
Mounting Type | 35mm DIN Rail |
Mounting Type | 35mm DIN rail (EN/IEC 60715) |
Mounting Type | 35mm DIN rail (fast clip) |
Mounting Type | 35mm DIN rail mount (EN/IEC 60715) |
Mounting Type | 35mm DIN Rail Mount (Fast Clip) |
Series | ABB Electrification |
Series | AF09Z, AF26Z, NFZ |
Series | CA4-04, CAL4-11, AF09Z, AF26Z, NFZ |
Series | ABB Electrification Cover Frames |
Size | 2x4 modules |
Size | 8 modules (2x4) |
Package Dimensions (L x W x H) | 14.29 IN x 9.61 IN x 1.26 IN |
Package Dimensions (L x W x H) | 36.2966 cm x 24.4094 cm x 3.2004 cm |
Package Weight (Imperial) | 1.930 L |
Package Weight (Metric) | 0.875 kg |
NE1.5X4WH6
The NE1.5X4WH6 Halogen-Free Wide Slot Wiring Duct design provides greater rigidity and allows for a wide range of wire/bundle sizes. Upper and lower scorelines for easy finger/sidewall section removal. UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 95 C (203 F). Halogen-Free, Polyphenylene Oxide (PPO). Mounting holes provided. 4.06" x 1.64" (103.1 mm x 41.7 mm) and 6' (1.83 m) long. Cover sold separately. Color White. 6 pieces per package.
NNC75X75WH2
The NNC75X75WH2 Halogen-Free Wide Slot Wiring Duct is used to route, protect, and manage wires near sensitive electronic equipment and in environments where heat resistance or public safety is a concern. UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 95 C (203 F). Halogen-Free, Polyphenylene Oxide (PPO). Mounting holes provided. 2.85" x 2.97" (72.4 mm x 75.4 mm) and 6.6' (2 m) long. Cover included. Color White. 5 pieces per package.
S289JLN
2 x 3 Inches Duct Spacer, High Impact Polystyrene Snap-Loc Intermediate Spacer For Use With Nonmetallic Ducts
S288JLN
2 x 3 Inches Duct Spacer, High Impact Polystyrene Snap-Loc Base Spacer For Use With Nonmetallic Ducts
Frequently Asked Questions
What is the maximum number of indoor stations?
The total address number of indoor stations is 250 in a single building or networked system.
What types of buildings can the Welcome M system be used in?
The Welcome M system can be used in single-family houses, multi-family buildings, high-rise buildings, and residential complexes.
How many outdoor stations can be installed?
Up to 9 outdoor stations can be installed in a video system with one building or villa.
What is the purpose of the gateway in the system?
The gateway ensures independent operation of each villa or building and links the entire group as a networked system.
What is the installation wiring type for the system?
The system typically uses a 2-wire bus for installation, allowing for looped or branch connections.
Is the Welcome M system compatible with existing wiring?
Yes, the system can often utilize existing wiring for upgrades from a bell system to a video system.
What is the voltage requirement for the system?
The Welcome M system operates on a 2-wire bus technology, but specific voltage requirements are not detailed in the document.
What safety precautions should be taken during installation?
While specific safety warnings are not detailed, it is recommended to follow standard electrical installation safety practices.
How can I troubleshoot common issues with the system?
Common troubleshooting steps are not explicitly mentioned in the document; refer to the technical assistant tool for guidance.
What maintenance is required for the Welcome M system?
The document does not specify maintenance requirements; regular checks of the system's functionality are advisable.
How to Install the 51026CF-W Outdoor Station
Installation and basic configuration guide for the 51026CF-W outdoor station, part of the ABB-Welcome door entry system.
Estimated time: 1h
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors, Flush-mounted installation socket, Rain hood
- Prepare for Installation
Ensure you have the necessary tools and supplies. Verify that the 51026CF-W outdoor station is compatible with ABB-Welcome system components and will be used with a suitable ABB flush-mounted installation socket and rain hood. Disconnect the mains power supply before proceeding.
- Mount the Outdoor Station
Mount the 51026CF-W outdoor station according to the general installation instructions and specific mounting guidelines provided in the manual. Ensure it is securely attached to the chosen installation socket and protected by a rain hood if applicable.
- Connect Wiring
Connect the necessary wiring to the terminals on the outdoor station module. Refer to the 'Terminal description' section for specific modules (e.g., Audio, Camera, Pushbutton, Keypad) to identify the correct terminals for bus connection, door opener, power supply, and any additional modules or devices.
- Set the Outdoor Station Address
Set the address for the outdoor station using the rotary switch (terminal 11 on the audio module). Addresses range from 1 to 9. For initial setup or specific configurations, you may need to set the address to '0' temporarily.
- Configure Door Lock Release Time
If applicable, adjust the door lock release time using the potentiometer (terminal 16 on the audio module). The time can be set from 1 to 10 seconds. If using a second lock, adjust its release time separately.
- Configure Pushbutton Functions
Configure the functions of the 1st and 2nd pushbuttons using the DIP switches (terminals 13 and 14 on the audio module). Options include calling an indoor station, switching on lighting, or calling a guard unit. Refer to the manual for specific DIP switch combinations.
- Configure Pushbutton Column Mode
Set the pushbutton configuration to single or double column mode using the DIP switch (terminal 13 on the audio module). This affects how buttons are arranged and numbered.
- Set Language for Voice Messages (if applicable)
If the audio module has a speech synthesis function, set the local language. With the outdoor station address set to '0', hold the 1st button for 3 seconds to enter setting mode, then click the button to select the language and hold to save.
- Configure Keypad Module Settings (if applicable)
If a keypad module is installed, access system settings by pressing '#* system password #' (default 345678). From here, you can set the device type (outdoor or gate station), modify the system password, change the door open code, set the voice message language, and enable/disable access control.
- Configure Display and Card Reader Module Settings (if applicable)
For modules with a card reader, register a master card by disconnecting and reconnecting power, then holding the 'program button' for 5 seconds within 30 seconds. Swipe any card to set it as the master card. Use the master card to access settings like programming cards, language, Wiegand output, door selection, and date/time.
- Enroll Cards for IC/NFC Module (if applicable)
For round pushbutton modules with NFC/IC card readers, create an admin card by swiping a card after powering up. Use the admin card to enter settings and enroll or delete user cards, enroll new admin cards, delete admin cards, or delete all users. You can also set the Wiegand format and switch validation on/off.
- Verify Installation
After completing the installation and configuration steps, verify that all modules are functioning correctly. Test calls to indoor stations, door lock release, and any other configured functions. Check the LED indicators for status information.
