A 6-hole bracket identified as BRACKET 6 HOLE 12-1/2. The sheet lists it as zinc plated. No additional dimensions or construction details are printed beyond the 12-1/2 in size reference in the title.

Bracket for 1-5/8 channel with a notched-down design. It is zinc plated. The sheet lists the length as 18 inches.

A left-hand slotted shelf bracket with a 16-inch size. It is zinc plated. The sheet identifies it as catalog number BRSSL16EG.

This is a bracket for 1-5/8 channel. The sheet identifies it as 6 inches long and zinc plated. It is catalog number BRC1626EG.

Bracket 1-5/8 Channel Wrap Around 12 in Zinc Plated. It is a wall mount bracket for 1-5/8 channel applications. The sheet identifies the finish as zinc plated and the length as 12 in.

Bracket for 1-5/8 channel with a 9 in length. It is zinc plated. The sheet identifies it as catalog number BRC1629EG.

Slotted shelf bracket, left hand, 6 in. It is zinc plated. The sheet identifies it as catalog number BRSSL6EG.

Steel bracket for 1-5/8" strut channel. It is made of carbon steel with an electro-galvanized finish. The bracket is 24" long, 2" wide, and 6-1/4" high. Mounting holes are 9/16" diameter, and the uniform load is 1,000 lbs. (4.45 kN) when mounted on 12 gauge channel.

Bracket for 1-5/8 channel with brace, 12 inches long. It is zinc plated. The sheet identifies it as catalog number BRC162B12EG.

Steel bracket for 1-5/8" strut channel. It is made of carbon steel with an electro-galvanized finish. The bracket is 18" long, 2" wide, and 6-1/4" high, with 9/16" mounting holes. Uniform load is 1,300 lb (5.78 kN) when mounted on 12 gauge channel.

Steel bracket for 1-5/8" strut channel. It is made of carbon steel with an electro-galvanized finish. The bracket is 30" long, 2" wide, and 6-1/4" high, with 9/16" mounting holes. Uniform load is 800 lbs. (3.56 kN) when mounted on 12 gauge channel.

Slotted shelf bracket, right handed, 16 in. It is zinc plated. The sheet identifies it as catalog number BRSSR16EG.
