Overview
- Specifically designed for type 4x food & beverage industry, indirect contact zone applications.
- Seams continuously welded and ground smooth
- Smooth Type 304 stainless steel lift-off bullet-style hinges
- Hinges are shielded by cover edges
- Hinged side of cover has provisions to allow direct flushing of hinge area
- 20-degree sloped top facilitates runoff of water and cleaning solutions and prohibits the placement of objects on the top of the enclosure
- 97-degree door opening
- Door edges are sloped 20 degrees at top and bottom edges to facilitate runoff
- Slanted flange trough collar prohibits pooling of fluids along the top edge of the enclosure opening
- Three-point latching operated by PowerGlide Type 316L padlocking stainless steel handles
Specifications
Application | Controls and Drives;Corrosive Environments;Hygienic Environments |
Application | Corrosive Environments; Controls and Drives; Hygienic Environments |
Color | Unpainted |
Conductive Panel | A60P60G |
Depth | 12 |
Depth | 305 mm |
Finish | Brushed #4 |
Height | 1,575 mm |
Height | 62 mm |
IP Rating | IP66 |
Material | Stainless Steel;Stainless Steel 304 |
Material | Stainless Steel 304 |
Modification Services | Yes |
NEMA Rating | 4X Watertight, corrosion-resistant |
NEMA Rating | 4X |
Panel | A60P60 |
Product Family | WaterShed |
Protection Rating | NEMA Type 12 |
Size | 62.00x63.00x12.00 in |
Thickness | 51.40mm (2.024") |
Thickness | 12 ga |
Thickness | 2.78 mm |
Type | Stainless Steel Freestanding Industrial Enclosures |
Type Number | Type 3R |
Weight | 463 lb |
Width | 63 |
Width | 1,600 |
Width | 1,600 mm |
Package Dimensions (L x W x H) | 68 IN x 38 IN x 75 IN |
Package Dimensions (L x W x H) | 172.72 cm x 96.52 cm x 190.5 cm |
Package Weight (Imperial) | 463.000 L |
Package Weight (Metric) | 210.017 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
How to Install the WS626312SS Enclosure
This guide provides step-by-step instructions for installing the WS626312SS enclosure, including mounting, wiring, and initial setup.
Estimated time: 45m
Tools needed:
Screwdriver, Hole saw, Punch tool
Supplies needed:
Watertight conduit hubs, Lockwashers, Mounting screws
- Prepare the enclosure
Install the external toothed lockwasher under one of the nuts securing the panel to ensure proper bonding between the panel and the enclosure.
- Cut conduit openings
Use a hole saw or Greenlee-type punch to cut the required holes for conduit entry in the top, bottom, or side walls of the enclosure, following the recommended sizes based on the conduit trade size.
- Install conduit hubs
Install the watertight conduit hubs according to the manufacturer's instructions, ensuring they fit securely into the openings you have cut.
