Contact for Pricing
Overview
- For use with Ultrx Series Products
- Features a Hi-Lo thread configuration for superior holding power and reduced stripping risk.
- Constructed from durable plated steel for excellent corrosion and wear resistance.
- Self-tapping design eliminates the need for pre-drilled holes, streamlining assembly.
- Measures 1/4-15 x .88 inches, ideal for nVent enclosure DIN bosses.
Specifications
Application | Controls and Drives;Corrosive Environments |
Color | Unpainted |
Finish | Plated |
Material | Steel |
Material | Mild Steel |
Material | Mild Steel;Steel |
Modification Services | Yes |
Mounting Type | Self-Tapping |
Product Family | Ultrx |
Series | ULTRX |
Size | 1/4-15 x .88 in |
Size | 1/4-15x.88 |
Type | Networking Accessories |
Weight | 0.14 lb |
Package Dimensions (L x W x H) | 7.25 IN x 5 IN x 0.5 IN |
Package Dimensions (L x W x H) | 18.415 cm x 12.7 cm x 1.27 cm |
Package Weight (Imperial) | 0.140 L |
Package Weight (Metric) | 0.064 kg |
SV1218
Pre-Fabricated Floor-Track Vertical Mounting Bracket with Supporting Horizontal Cross Bar, 12 Inch or 18 Inch Height, For 4 Inch Square of 4-11/16 Inch Square Boxes, Deep or Shallow, with Standard Device Covers (Mud Rings)
BMB24
This is a 24" electrical box mounting bracket that mounts a 1-1/2" electrical box to studs on 24" centers. It is made of pre-galvanized steel. The finish/color is silver.
How to Install the ULTRX Fiberglass WiFi Cabinet
This guide provides step-by-step instructions for mounting and wiring the ULTRX Fiberglass WiFi Cabinet for optimal performance.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the cabinet
Secure the ULTRX Fiberglass WiFi Cabinet to the wall using the provided mounting screws. Ensure the cabinet is level and firmly attached.
- Install the panel
If using a steel panel, install the Panel Bracket Kit (catalog number UUPB) to allow for panel adjustment. Mount the panel inside the cabinet using the self-tapping screws.
- Connect the wiring
Use wire strippers to prepare the wires and connect them to the terminal connectors inside the cabinet. Ensure all connections are secure and insulated.
- Verify electrical connections
Use a multimeter to check the voltage and continuity of the connections. Ensure that all readings are within the specified range to confirm proper installation.
- Calibrate the cabinet
Adjust any internal settings as per the manufacturer's specifications to ensure optimal performance of the WiFi cabinet.
