Contact for Pricing
Overview
- For use with Ultrx Series Products
- Flat slotted drive for convenient operation with a standard flat head screwdriver.
- Direct replacement for standard quarter-turn latches, enhancing enclosure security.
- Specifically designed for seamless integration with nVent Ultrx enclosures.
- Polished finish for a professional aesthetic in industrial and commercial settings.
Specifications
Application | Corrosive Environments; Controls and Drives |
Application | Controls and Drives;Corrosive Environments |
Color | Unpainted |
Finish | Polished |
Insert Type | Screw driver slot |
Key Type | Screw Driver |
Material | Stainless Steel 316L |
Material | Stainless Steel;Stainless Steel 316L |
Modification Services | Yes |
Product Family | Ultrx |
Type | Industrial Door Mounting and Locks |
Weight | 0.18 lb |
Works With | NEMA |
Package Dimensions (L x W x H) | 7.1 IN x 5 IN x 0.5 IN |
Package Dimensions (L x W x H) | 18.034 cm x 12.7 cm x 1.27 cm |
Package Weight (Imperial) | 0.180 L |
Package Weight (Metric) | 0.082 kg |
How to Install the ULTRX Fiberglass Enclosure
This guide provides step-by-step instructions for installing and configuring the ULTRX fiberglass enclosure, ensuring proper mounting and wiring.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors, Grounding device
- Mount the enclosure
Secure the ULTRX enclosure to the desired location using the provided mounting brackets and screws. Ensure the enclosure is level and firmly attached.
- Connect the grounding device
Attach the grounding device to the designated grounding point inside the enclosure. Use appropriate tools to ensure a secure connection.
- Wire the internal components
Connect the internal components to the terminal connectors according to the wiring diagram provided. Use a multimeter to verify connections are secure and functioning.
- Configure the enclosure settings
Adjust any internal settings or configurations as needed based on the application requirements. Refer to the specific configuration guide for detailed instructions.
- Calibrate the enclosure
Perform any necessary calibration procedures to ensure the enclosure operates correctly. Follow the calibration instructions specific to the installed components.
Frequently Asked Questions about nVent
What industries and applications are nVent products used for?
nVent products are engineered for critical infrastructure and industrial applications across multiple demanding sectors. Key markets include Construction, Data Centers, Defense, Healthcare, Mining, Oil & Gas Refineries, Power Plants, Rail/Transit, Renewable Energy, Security, Ship Building, Steel Mills, Telecom, and Utilities. Their solutions are designed to withstand extreme environmental conditions, with temperature ranges from -55°C to 105°C and specialized features like UV resistance, oil resistance, and flame resistance.
What environmental ratings do nVent products have?
nVent enclosures feature comprehensive environmental ratings, including UL 508A, CSA, and NEMA Type 1, 2, 3, 4, 4X, 12, and 13 certifications. They are rated IEC 60529 IP66, providing robust protection against dust, water, and corrosion in both indoor and outdoor environments. These products operate effectively in temperatures ranging from -40°F to 266°F, with enhanced UV inhibitors for outdoor weathering and oil-resistant gaskets for superior sealing.
What accessories are available for nVent products?
nVent offers a comprehensive range of accessories across multiple product lines, including EMC accessories like bonding cable clamps and strain reliefs, inline accessories such as lock inserts and mounting brackets, CONCEPT accessories including panel conversion kits and rack-mount angles, and seismic accessories for specialized mounting requirements. Key accessory categories include grounding kits, DIN rail mounting solutions, panel supports, handles, and various mounting hardware compatible with different enclosure types.
What certifications and standards do nVent products comply with?
nVent products meet critical international certifications including UL (United States), CSA (Canada), CE (European Community), and EAC (Russia). Our products are designed to comply with rigorous industrial standards such as NEMA enclosure ratings, IEC 60529 IP ratings, and international safety standards across multiple industrial markets including oil & gas, power, manufacturing, and infrastructure.
What is nVent's warranty policy?
nVent offers a standard 18-month warranty from invoicing date for most automation products, covering defects in workmanship and materials. The warranty requires proper transportation, handling, storage, and installation within specified environmental conditions. Warranty coverage includes repair or replacement at nVent's discretion, with certain conditions such as authorized service repairs and operation within designed capacity limits.
What technical support does nVent offer?
nVent offers comprehensive technical support through multiple global contact centers across North America, South America, Europe, Middle East, India, and Asia. Customers can reach technical experts by phone at regional numbers, with the North American headquarters in Minneapolis, MN providing primary support at +1.763.421.2240. Additionally, nVent provides online support resources through their website, including CAD drawing downloads and an 'Ask The Expert' feature to assist with product technical inquiries.
