Contact for Pricing
Overview
- Attaches magnetically between two racks or other metal surface
- Adjusts to fill in space between racks, from 10- to 60-inch (250 mm to 1500 mm)
- Can easily be removed and reapplied as your computer room needs change
- Express containment system includes magnetic mounting for quick-install
- Compatible with standard 19-inch racks for data centers, telecom, and colocation facilities
Specifications
Application | Datacom and Telecom Equipment;Networking, Storage and Data Center;Telecom and Data Protection |
Application | Networking, Storage and Data Center; Datacom and Telecom Equipment; Telecom and Data Protection |
Color | Black |
Color | Black;Black, Ral 9005 |
Color | Jet Black |
Color Code | RAL 9005 |
Consist Of | Rack Gap Panel, 42-45 Rack Units |
Depth | 102 mm |
Depth | 4 in |
Finish | Powder Coated |
Height | 85.25 in |
Height | 44 IN |
Height | 2,165 mm |
Material | Mild Steel |
Material | Steel |
Mounting Type | 19-inch EIA rack mounting |
Product Family | ProLine Containment System |
Series | nVent Express |
Size | 85.25 x 60.00 x 4.00 inch |
Size | 85.25x60.00x4.00 |
Type | Aisle Containment |
Weight | 2 lb |
Width | 60 in |
Width | 1,524 mm |
Package Dimensions (L x W x H) | 83.3 IN x 61.5 IN x 10 IN |
Package Dimensions (L x W x H) | 211.582 cm x 156.21 cm x 25.4 cm |
Package Weight (Imperial) | 35.000 L |
Package Weight (Metric) | 15.876 kg |
How to Install the ProLine Adjustable Rack Gap Panel
This guide provides step-by-step instructions for installing the ProLine Adjustable Rack Gap Panel securely between two metal surfaces.
Estimated time: 15m
Supplies needed:
ProLine Adjustable Rack Gap Panel
- Determine the installation position
Identify the best location on the cabinet or steel surface for mounting the ProLine Adjustable Rack Gap Panel. Ensure that the surface is clean and free of obstructions.
- Attach the panel to the surface
Remove the ProLine Adjustable Rack Gap Panel from the packaging. Stand it vertically with the graphics facing you. Position the bottom of the panel against the cabinet side panel, then pivot the top into place, allowing the magnets to snap securely.
- Extend the retractable material
With the panel securely mounted, grab the handle and gently pull the spring-loaded material from the case. Continue pulling until the magnets in the handle side contact the adjacent surface, ensuring it is plumb and properly positioned.
