Overview
- Unique counterflow aluminum core for high efficiency and high performance heat transfer
- Engineered for temperature extremes, corrosive environments and wind driven rain
- Models for 24 VDC, 48 VDC, 115 VAC and 230 VAC power supplies
- Variable speed blowers standard on DC powered units for quiet running
- Filterless design for low maintenance and easy cleaning
- Painted galvanized or stainless steel sheet-metal cover for rugged factory and outdoor environments
- Easy-mount flanges for simple installation
- Surface or recessed mount capable
- Every unit functionally tested before shipping
- Mounting hardware, gaskets and user manual furnished with the unit
Specifications
Application | Power Distribution; Controls and Drives |
Capacity Watts Per degr.C | 25 W |
Capacity Watts Per degr.F | 14 W |
Color | Light Gray |
Color Code | RAL 7035 |
Depth | 180 mm |
Depth | 7.1 in |
Dimensions | 23 x 12 x 7.1 in |
Finish | Powder Coated |
Height | 23 IN |
Height | 584 mm |
Housing Material | Mild Steel |
IP Rating | IP66 |
Material | Metal |
Material | Aluminum, Mild Steel |
Material | Mild Steel |
Max Current | 0.6 A |
Max Watts Per °F | 14 W |
Max Watts Per degr.C | 25 W |
Max Watts Per degr.F | 14 W |
Mechanical Advantage | Mild steel sheet metal standard |
Mounting | Surface Mounted |
Mounting Type | Surface or Recess Mount |
Mounting Type | Surface or Recessed |
Nema Rating | Type 12, 4, 4X (optional) |
NEMA Rating | 4 Watertight |
Nominal Voltage | 115 V |
Operating Temperature | -40-149 °F |
Operating Temperature | -40-65 °C |
Power Consumption | 14 W per deg F max |
Product Family | ClimaGuard |
Protection Rating | NEMA Type 4 |
Series | ClimaGuard |
Series | ClimaGuard TX23 |
Temperature Range | -40 to 149 deg F |
Thickness | 1.21 mm |
Thickness | 18 ga |
Type | Heat Exchangers |
Voltage AC | 100-120 V |
Voltage Rating | 115 VAC |
Weight | 13.6 kg |
Weight | 32 lb |
Width | 305 mm |
Width | 12 IN |
Package Dimensions (L x W x H) | 23.5 IN x 14.5 IN x 9.5 IN |
Package Dimensions (L x W x H) | 59.69 cm x 36.83 cm x 24.13 cm |
Package Weight (Imperial) | 32.000 L |
Package Weight (Metric) | 14.515 kg |
How to Install the TX23 Heat Exchanger
This guide provides step-by-step instructions for installing the TX23 heat exchanger, including mounting, wiring, and initial setup.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Gasket kit, Power cord
- Inspect the heat exchanger
Check for any visible damage to the heat exchanger before installation. Ensure all components are intact and functional.
- Prepare the mounting area
Determine if the unit will be surface or recess mounted. Use the provided cutout dimensions to prepare the enclosure opening accordingly.
- Install gaskets
Using the gasket kit provided, attach gaskets to the heat exchanger to ensure a proper seal.
- Mount the heat exchanger
Secure the heat exchanger to the enclosure using the mounting screws provided. Torque the screws to 25 in-lbs (2.82 Nm).
- Connect the power supply
Refer to the unit nameplate for electrical requirements. Connect the power cord to a properly grounded power supply. Avoid using an extension cord.
- Test functionality
Power on the unit and allow it to run for several minutes. Listen for excessive noise or vibration, which may indicate a problem.
