Contact for Pricing
Overview
- Set screws and gasket are included
- White aluminum cable access cap is included
- Assembled Syspend 180 HMI Arm System has a max weight load of 180 lb. (81.6 kg)
- Integrated safety stop and maintenance-free bearings
- Includes installation instructions, gaskets, and tube setscrews
Specifications
Application | Controls and Drives |
Color | Light Gray |
Color | Lt Gray |
Color Code | RAL 7035 |
Depth | 4.88 |
Depth | 124 |
Depth | 124 mm |
Finish | Powder Coated |
Height | 158 mm |
Height | 6.22 |
Height | 158 |
Material | Aluminum |
Material | Die-Cast Aluminum |
Modification Services | Yes |
Product Family | Syspend 180-Max |
Protection Rating | IP65 |
Series | Syspend 180-Max |
Size | 8.98x7.68x3.94 |
Type | Syspend 180-Max |
Weight | 2.27 kg |
Weight | 5.4 lb |
Width | 3.94 |
Width | 100 |
Width | 100 mm |
Package Dimensions (L x W x H) | 9.7 IN x 9.1 IN x 5.2 IN |
Package Dimensions (L x W x H) | 24.638 cm x 23.114 cm x 13.208 cm |
Package Weight (Imperial) | 5.400 L |
Package Weight (Metric) | 2.449 kg |
How to Install the SYSPEND 180-MAX Suspension System
This guide provides step-by-step instructions for mounting and configuring the SYSPEND 180-MAX suspension system for optimal performance.
Estimated time: 1h
Tools needed:
Screwdriver, Spirit level, Wrench
Supplies needed:
Mounting screws (M6), Lock washers, Seals
- Prepare the mounting surface
Ensure the mounting surface is smooth and flat to avoid issues with load and adjustment. Check for any obstructions that may interfere with installation.
- Mount the suspension system
Lift the enclosure under the coupling (support necessary) and attach the lock washers to the screws. Fit the screws through the horizontal section into the coupling and tighten them with a torque of 6 Nm.
- Adjust the vertical and horizontal tubes
Loosen the screws on the vertical and horizontal tubes. Adjust to the desired position and then tighten the screws with a torque of 10 - 12 Nm to secure the alignment.
- Check the alignment
Use a spirit level to verify that the vertical and horizontal tubes are properly aligned. Make any necessary adjustments before finalizing the installation.
- Install the seals
Press the seals smoothly into place to ensure a proper fit and prevent any potential leaks or issues with the system's integrity.
