Contact for Pricing
Overview
- Gasket and mounting hardware are included
- Assembled Syspend 180 HMI Arm System has a max weight load of 180 lb. (81.6 kg)
- Compatible with Flange Coupling and Flange Elbow Coupling
- Die-cast aluminum construction for durability and corrosion resistance
- Light gray (RAL 9005) finish for a professional aesthetic
Specifications
Application | Controls and Drives |
Color | Light Gray |
Color Code | RAL 7035 |
Depth | 83 mm |
Depth | 3.27 |
Depth | 83 |
Finish | Powder Coated |
Height | 1.141 in |
Height | 29 mm |
Height | 1.14 |
Height | 29 |
Material | Aluminum |
Modification Services | Yes |
Mounting Type | Flange Coupling/Flange Elbow Coupling |
Product Family | Syspend 180-Max |
Protection Rating | IP65 |
Series | Syspend 180-Max |
Size | 1.14" x 4.92" x 3.27" |
Size | 1.14x4.92x3.27 inches (29x125x83mm) |
Type | Syspend 180-Max |
Weight | 0.25 kg |
Weight | 0.9 lb |
Width | 125 |
Width | 4.92 in |
Width | 125 mm |
Package Dimensions (L x W x H) | 5.8 IN x 3.6 IN x 3.8 IN |
Package Dimensions (L x W x H) | 14.732 cm x 9.144 cm x 9.652 cm |
Package Weight (Imperial) | 0.900 L |
Package Weight (Metric) | 0.408 kg |
How to Install the S1MAG Suspension System
This guide provides step-by-step instructions for installing and configuring the S1MAG suspension system, ensuring proper mounting and adjustments.
Estimated time: 1h
Tools needed:
Screwdriver, Spirit level, Torque wrench
Supplies needed:
Mounting screws, Lock washers, Seals
- Mount the suspension system
Secure the suspension system to the wall or machine using the appropriate mounting screws. Ensure the surface is smooth and flat to avoid load issues.
- Attach the coupling components
Fit the coupling components to the suspension system, ensuring to use lock washers. Tighten the screws to a torque of 6 Nm.
- Adjust the vertical and horizontal tubes
Loosen the adjustment screws and align the tubes using a spirit level. Once aligned, tighten the screws to a torque of 10-12 Nm.
- Install the seals
Press the seals smoothly into place to ensure a tight fit. This is crucial for maintaining the system's integrity.
- Verify the installation
Check all connections and ensure that the system is stable and secure. Perform a final inspection to confirm that all screws are tightened to the specified torque.
