nVent RF-12 - RF Solar Combiner Box, grounded, 17.32x15.32x6.65, 12 contacts, Fiberglass
nVent

RF-12

UPC: 635394585743

Contact for Pricing

Overview

The nVent RF-12 Solar Combiner Box (SKU: RF-12) is a grounded, fiberglass enclosure designed for efficient and safe power consolidation in photovoltaic (PV) systems. Measuring 17.32x15.32x6.65 inches, this robust unit combines power from up to 12 solar strings. Its durable fiberglass construction provides NEMA 4x, IP68, and UV resistance, ensuring longevity in harsh outdoor conditions. Key features include oversized busbars to minimize electrical losses and improve system efficiency, contributing to enhanced inverter protection. The RF-12 facilitates the transition to larger gauge wires, reducing transmission voltage drop. Assembled in the USA, it meets IEC and UL standards. This combiner box simplifies solar array connections, making it an essential component for solar installers and system integrators seeking reliable power management. Its design supports improved safety with internal fuse holders and circuit breakers, while prearranged configurations reduce on-site installation time and costs. The RF-12 is compatible with any brand of solar panel, offering versatile application for new or expanded solar arrays.
  • Combines power from up to 12 solar strings
  • Durable fiberglass enclosure with NEMA 4x, IP68, and UV resistance
  • Oversized busbars minimize electrical losses and voltage drop
  • Grounded design for enhanced system safety
  • Compact dimensions: 17.32x15.32x6.65 inches
  • Connector Type: Screw Clamp
  • Maximum Current Per Terminal: 24A
  • Maximum Fuse Size: 30A

Specifications

Application
Controls and Drives; Power Distribution; Power Connections; Corrosive Environments
Color
Light Gray
Color Code
RAL 7035
Depth
169 mm
Depth
6.65 in
Finish
Smooth Matte
Height
440 mm
Height
17.32 in
Ip Rating
IP68
Material
Fiberglass
Max Current
288 A
Max Heating Cable Output Wire Size
#3/0 - 350 kcmil
Max Power Supply Input Wire Size
#6 - #14
Nema Rating
NEMA 4X
Nominal Voltage
1,000 V
Nominal Voltage Type
AC/DC
Number of Contacts
12
Poles
12
Protection Rating
NEMA Type 3
Series
RF
Size
17.32x15.32x6.65 in
Thickness
3.3 mm
Thickness
0.13 in
Type
Fiberglass and Thermoplastic Terminal and Junction Boxes
Type
Fiberglass and Thermoplastic Industrial Terminal and Junction Boxes
Weight
7.37 lb
Width
15.32 in
Width
389 mm
