Contact for Pricing
Overview
- 60A, 208V, 3-phase power distribution
- 1U rackmount aluminum chassis
- C13 and C19 combination outlets
- 460P9 input connection for 3-phase integration
- Manufactured by nVent (SKU: RB0952)
- Adjustable Toolless Mounting
Specifications
Application | Datacom and Telecom Equipment; Telecom and Data Protection; Networking, Storage and Data Center |
Color | Black |
Connection Type | 460P9 input connection |
Current Rating | 60 A |
Depth | 75 mm |
Length | 1,780 |
Material | Aluminum |
Mounting Type | Rackmount |
Number of Sockets | 42 |
Poles | 3-Phase |
Product Type | Socket Strip |
Series | RackPower Basic |
Size | 1U |
Socket Type | IEC C13 |
Type | Socket Strips |
Voltage AC | 208 V |
Voltage Rating | 208 VAC |
Width | 56 |
With Switch | Yes |
Package Dimensions (L x W x H) | 77.9 IN x 10.3 IN x 5.1 IN |
Package Dimensions (L x W x H) | 197.866 cm x 26.162 cm x 12.954 cm |
Package Weight (Imperial) | 33.100 L |
Package Weight (Metric) | 15.014 kg |
P24D27M
This Panduit G5 Monitored Input PDU features (18) C13 and (6) C19 outlets. It is a 30 amp, 208 V, three phase PDU with a NEMA L15-30P input plug and a 10 foot (3m) power cord.
How to Install the RB0952 Power Distribution Unit (PDU)
This guide provides step-by-step instructions for installing and configuring the RB0952 Power Distribution Unit in a server cabinet.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the PDU
Secure the RB0952 PDU to the server cabinet using the provided mounting pegs. Ensure the unit is level and firmly attached.
- Connect the power supply
Use terminal connectors to connect the power supply wires to the designated input terminals on the RB0952. Ensure all connections are tight and secure.
- Verify electrical connections
Utilize a multimeter to check the voltage at the output terminals of the RB0952. Confirm that the readings are within the specified range to ensure proper functionality.
- Configure the PDU settings
Access the configuration interface of the RB0952 using the provided software. Set the desired parameters such as load limits and monitoring options.
- Calibrate the PDU
Follow the calibration procedure outlined in the user manual to ensure accurate power monitoring and distribution. Adjust settings as necessary based on the calibration results.
Frequently Asked Questions about nVent
What industries and applications are nVent products used for?
nVent products are engineered for critical infrastructure and industrial applications across multiple demanding sectors. Key markets include Construction, Data Centers, Defense, Healthcare, Mining, Oil & Gas Refineries, Power Plants, Rail/Transit, Renewable Energy, Security, Ship Building, Steel Mills, Telecom, and Utilities. Their solutions are designed to withstand extreme environmental conditions, with temperature ranges from -55°C to 105°C and specialized features like UV resistance, oil resistance, and flame resistance.
What environmental ratings do nVent products have?
nVent enclosures feature comprehensive environmental ratings, including UL 508A, CSA, and NEMA Type 1, 2, 3, 4, 4X, 12, and 13 certifications. They are rated IEC 60529 IP66, providing robust protection against dust, water, and corrosion in both indoor and outdoor environments. These products operate effectively in temperatures ranging from -40°F to 266°F, with enhanced UV inhibitors for outdoor weathering and oil-resistant gaskets for superior sealing.
What accessories are available for nVent products?
nVent offers a comprehensive range of accessories across multiple product lines, including EMC accessories like bonding cable clamps and strain reliefs, inline accessories such as lock inserts and mounting brackets, CONCEPT accessories including panel conversion kits and rack-mount angles, and seismic accessories for specialized mounting requirements. Key accessory categories include grounding kits, DIN rail mounting solutions, panel supports, handles, and various mounting hardware compatible with different enclosure types.
What certifications and standards do nVent products comply with?
nVent products meet critical international certifications including UL (United States), CSA (Canada), CE (European Community), and EAC (Russia). Our products are designed to comply with rigorous industrial standards such as NEMA enclosure ratings, IEC 60529 IP ratings, and international safety standards across multiple industrial markets including oil & gas, power, manufacturing, and infrastructure.
What is nVent's warranty policy?
nVent offers a standard 18-month warranty from invoicing date for most automation products, covering defects in workmanship and materials. The warranty requires proper transportation, handling, storage, and installation within specified environmental conditions. Warranty coverage includes repair or replacement at nVent's discretion, with certain conditions such as authorized service repairs and operation within designed capacity limits.
What technical support does nVent offer?
nVent offers comprehensive technical support through multiple global contact centers across North America, South America, Europe, Middle East, India, and Asia. Customers can reach technical experts by phone at regional numbers, with the North American headquarters in Minneapolis, MN providing primary support at +1.763.421.2240. Additionally, nVent provides online support resources through their website, including CAD drawing downloads and an 'Ask The Expert' feature to assist with product technical inquiries.
