nVent PTOD2212SS - ProLine Overlapping Doors, 84.21x46.89x0.00, Brushed, Stainless Steel 304
nVent

PTOD2212SS

UPC: 783510197810

Documents & Media
Installation Instructions

Contact for Pricing

Overview

The nVent ProLine Overlapping Doors (SKU: PTOD2212SS) deliver a robust, dust-tight sealing solution engineered for industrial enclosures requiring full-width access. Constructed from high-grade Stainless Steel 304 with a durable brushed finish, these doors are designed to meet the demands of harsh environments while ensuring long-term performance and corrosion resistance. The ProLine series is a trusted choice for professionals who prioritize reliability, ease of maintenance, and operational efficiency in critical applications. ProLine Overlapping Doors are specifically engineered to provide a seamless, full-width opening for enclosures measuring 800mm, 1000mm, 1200mm, and 1600mm in width. The primary door features a 3-point roller latch system, activated by a ProLine flush swing handle, ensuring a secure and dust-tight seal when closed. This design minimizes air infiltration and particulate contamination, making it ideal for cleanroom environments, electronics manufacturing, pharmaceutical production, and other controlled industrial settings where contamination control is paramount. The brushed Stainless Steel 304 construction offers exceptional durability, resistance to corrosion, and ease of cleaning, aligning with industry standards for hygiene and longevity. The overlapping door design eliminates gaps, providing a tight seal that enhances the integrity of the enclosure while allowing for quick and unobstructed access when needed. This feature is particularly valuable in applications where frequent access is required without compromising the enclosure's protective capabilities. Professionals in industries such as semiconductor manufacturing, food and beverage processing, and automotive assembly rely on the ProLine series for its proven performance and compatibility with nVent's comprehensive line of enclosure solutions. The flush swing handle design ensures smooth operation and ergonomic usability, reducing operator fatigue and improving workflow efficiency. Additionally, the ProLine Overlapping Doors are designed for easy installation and integration with existing nVent enclosure systems, streamlining the setup process and reducing downtime. nVent, a global leader in thermal management and electrical solutions, is renowned for its commitment to innovation, quality, and customer support. With a legacy of delivering high-performance products, nVent's ProLine series embodies the company's dedication to providing solutions that meet the evolving needs of industrial professionals. The PTOD2212SS model, with its precise dimensions and robust construction, is a testament to nVent's expertise in designing products that enhance operational safety, efficiency, and compliance with industry regulations. Whether you are outfitting a new facility or upgrading an existing enclosure system, the nVent ProLine Overlapping Doors offer a reliable, high-quality solution that delivers on performance, durability, and ease of use. Trusted by industry leaders worldwide, the ProLine series stands as a benchmark for industrial enclosure doors, ensuring that your operations remain protected, efficient, and compliant.
  • Dust-tight seal with 3-point roller latch system for superior contamination control
  • Full-width access for enclosures up to 1600mm wide
  • Brushed Stainless Steel 304 construction for corrosion resistance and durability
  • Flush swing handle for ergonomic and smooth operation
  • Designed for easy installation and integration with nVent enclosure systems

Specifications

Application
Controls and Drives;Power Distribution
Application
Controls and Drives; Power Distribution
Color
Unpainted
Dimensions
28W x 10D x 10H IN
Dimensions
84.21 x 46.89 in
Finish
Brushed
Fits Frame
2200 x1200 mm
Fits Frame
1400 x 1200 mm
Material
Stainless Steel;Stainless Steel 304
Material
Stainless Steel 304
Modification Services
Yes
Product Family
ProLine
Size
84.21x46.89x0.00 in
Thickness
1.9 mm
Thickness
14 ga
Thickness
51.40mm (2.024")
Type
External Mounting for ProLine Industrial Enclosures
Weight
150 lb
Works With
NEMA
Package Dimensions (L x W x H)
87 IN x 27.5 IN x 7 IN
Package Dimensions (L x W x H)
220.98 cm x 69.85 cm x 17.78 cm
Package Weight (Imperial)
150.000 L
Package Weight (Metric)
68.040 kg
