nVent PTOD1816 - ProLine Overlapping Doors, 68.46x62.64x0.00, Painted
nVent

PTOD1816

UPC: 783510197834

Documents & Media
Installation Instructions

Contact for Pricing

Overview

The nVent ProLine Overlapping Doors (SKU: PTOD1816) offer a robust and reliable door system designed to provide secure access and environmental protection for industrial enclosures. Engineered by nVent, a trusted leader in electrical enclosure solutions, these doors are specifically crafted to fit the full-width open fronts of 800, 1000, 1200, and 1600-mm wide ProLine frames. This particular model, with dimensions of 68.46x62.64 inches and a painted finish, ensures a precise fit and durable performance in demanding industrial environments. The primary door of this system is engineered for exceptional sealing capabilities, featuring a dust-tight seal that is critical for protecting sensitive electrical and electronic components from ingress of dust, moisture, and other contaminants. This superior sealing is achieved through an integrated 3-point roller latch system. This system is intuitively operated by a ProLine flush swing handle, which provides a secure locking mechanism while maintaining a clean, unobtrusive profile on the enclosure door. The flush design minimizes protrusions, enhancing safety and preventing snagging in busy industrial settings. Key benefits of the nVent ProLine Overlapping Doors include: * **Enhanced Environmental Protection:** The dust-tight seal safeguards internal equipment from particulate matter, crucial for maintaining operational integrity and extending component lifespan. * **Secure Access Control:** The 3-point roller latch system, operated by the flush swing handle, offers reliable security and easy access for maintenance and operational checks. * **Durable Construction:** Manufactured by nVent, these doors are built to withstand the rigors of industrial applications, ensuring long-term reliability. * **Seamless Integration:** Designed to perfectly complement ProLine frames, ensuring a straightforward installation process and a cohesive enclosure solution. * **Aesthetic and Functional Design:** The painted finish provides a professional appearance and added corrosion resistance, while the flush handle design prioritizes safety and operational efficiency. These overlapping doors are an essential component for a wide range of industrial applications, including manufacturing facilities, power generation plants, telecommunications infrastructure, and data centers. Their robust design and sealing capabilities make them ideal for housing control panels, power distribution units, and other critical electrical equipment. The UNSPSC code 39121334 further categorizes this product within the industrial machinery and equipment sector, highlighting its specialized nature. Manufactured in the US, the PTOD1816 model embodies nVent's commitment to quality and innovation in providing comprehensive enclosure solutions for the modern industrial landscape.
  • overlapping primary/adjacent door design allows unobstructed access
  • Furnished with a ProLine flush swing handle
  • Removable door bar is included on each door
  • Primary door is hinged on the right side
  • Durable painted finish for enhanced longevity and aesthetics

Specifications

Application
Controls and Drives; Power Distribution
Color
Light Gray
Color
Painted
Color Code
RAL 7035
Dimensions
1739 x 1591 mm
Dimensions
68.46 x 62.64 in
Finish
Powder Coated
Fits Frame
1800 x 1600 mm
IP Rating
IP66
Material
Steel
Material
Mild Steel
Modification Services
Yes
Mounting Type
Modular/Overlapping
Nema Rating
Type 4X
Product Family
ProLine
Series
ProLine
Size
68.46x62.64
Size
68.46x62.64 in
Size
68.46x62.64x0.00 in
Thickness
1.9 mm
Thickness
14 ga
Type
External Mounting for ProLine Industrial Enclosures
Weight
131.5 lb
Package Dimensions (L x W x H)
70.3 IN x 34.9 IN x 6.3 IN
Package Dimensions (L x W x H)
178.562 cm x 88.646 cm x 16.002 cm
Package Weight (Imperial)
131.500 L
Package Weight (Metric)
59.648 kg
