nVent
PSFD20612BNS
UPC: 783510158477
Contact for Pricing
Overview
- Fan bank promotes air flow through cabinet to exhaust into hot aisle
- Independently powered fans provide redundant cooling
- Top and side cover configurations prevent recirculation of hot exhaust air
- Top cover configuration allows for easy routing of network cables, pre-terminated cables and patch panels
- Side-less models allow for easy installation in ganging applications
- Three-point locking swing handle allows for easy but controlled access; two keys included
- Common profiles allow ganging of server and networking cabinets
- Models without sides fit together quickly for easy installation in ganged applications
- Three-point locking pushbutton swing handle on front door provides easy but controlled access; two keys included.
- Rear doors are split for easy access and include a low-profile, locking swing handle
Specifications
Application | Networking, Storage and Data Center |
Color | Jet Black |
Color | Black |
Color Code | RAL 9005 |
Depth | 1,199 mm |
Depth | 47.22 |
Depth | 1,199 |
Finish | Powder Coated |
Finish | Black;Powder Coating |
Height | 2,085 mm |
Height | 82.08 |
Height | 2,085 |
Material | Steel |
Material | Mild Steel |
Material | Mild Steel;Steel |
Modification Services | Yes |
Mounting Type | Free-Standing |
Product Family | ProLine |
Rack Angle | PRA1920THL1 |
Rack Units | 42 |
Series | ProLine FloTek FD Server Cabinet |
Series | ProLine FloTek FD |
Side Covers Included | No |
Sides | Without sides |
Size | 2000x600x1200mm |
Thickness | 1.52 mm |
Thickness | 16 |
Thickness | 1.52 |
Type | Data Networking Freestanding Cabinets |
Weight | 580 lb |
Width | 23.58 |
Width | 599 |
Width | 599 mm |
Package Dimensions (L x W x H) | 72 IN x 18 IN x 72 IN |
Package Dimensions (L x W x H) | 182.88 cm x 45.72 cm x 182.88 cm |
Package Weight (Imperial) | 580.000 L |
Package Weight (Metric) | 263.088 kg |
