Overview
- Side hinge brackets are used to mount the swing frame, allowing free access above and below the swing frame
- Used with any height enclosure and hinged on the right or left
- Furnished with hinges, two quarter-turn latches and mounting hardware
- Complies with ANSI/EIA RS-310-D rack mounting standards:
- Swing-Out Rack Frame assemblies are supplied with mounting supports; Swing-Out Rack Frames can also be installed in right, left or both bays of 1200-mm wide frames using center uprights
- Swing-out mounting supports mount to inside of frame at any vertical location
- Mounting supports and swing-out frame can be located at a variable depth using grid straps; swing is reduced when located at a depth other than front mounted
Specifications
Application | Controls and Drives |
Color | Light Gray |
Color | Gray |
Color | Grey |
Color Code | RAL 7035 |
Finish | Powder Coated |
Finish | Powder Coating |
Fits Frame Width | 600 mm |
Material | Steel |
Material | Mild Steel |
Material | Mild Steel;Steel |
Modification Services | Yes |
Mounting Type | Swing-Out, Hinges |
Product Family | ProLine |
Rack Units | 16 |
Series | PSF |
Series | Partial Swing-Out Rack Frame |
Size | fits 600mm wide in |
Size | 600mm wide |
Size | 600mm wide, 800-mm tall |
Thickness | 2.66 mm |
Thickness | 12 ga |
Thickness | 51.40mm (2.024") |
Type | Internal Mounting for ProLine Industrial Enclosures |
Weight | 17.32 lb |
Works With | NEMA |
Package Dimensions (L x W x H) | 33.25 IN x 22.5 IN x 4.5 IN |
Package Dimensions (L x W x H) | 84.455 cm x 57.15 cm x 11.43 cm |
Package Weight (Imperial) | 17.320 L |
Package Weight (Metric) | 7.856 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
How to Install the Swing Frame
This guide provides step-by-step instructions for mounting the swing frame using the appropriate screws and nuts.
Estimated time: 30m
Tools needed:
Screwdriver
Supplies needed:
M5x10 self-tapping screws, M6x16 screws, M6 cage nuts
- Select mounting screws
Choose between M5x10 self-tapping screws or M6x16 screws with M6 cage nuts for mounting the swing frame.
- Mount the swing frame
Secure the swing frame to the designated area using the selected screws. Ensure that the frame is level and firmly attached.
- Verify installation
Check that the swing frame is securely mounted and does not wobble. Ensure all screws are tightened properly.
