Contact for Pricing
Overview
- Conductive steel brace; furnished in pairs
- Braces can be installed on existing systems without removing the panel
- Constructed from durable, corrosion-resistant galvanized steel
- Conductive finish ensures electrical continuity for grounding and static dissipation
- Retrofit-friendly design allows installation without panel removal
Specifications
Application | Power Distribution; Controls and Drives |
Color | Unpainted |
Finish | Galvanized |
Fits Panel Width | 1,600 mm |
Material | Galvanized Steel |
Material | Mild Steel |
Modification Services | Yes |
Mounting Type | Bracket Mounting with BV-M6 Fastener |
Product Family | ProLine |
Series | ProLine G2 |
Size | fits 1600mm |
Size | 1600mm Width |
Thickness | 3.04 mm |
Thickness | 11 ga |
Type | Internal Mounting for ProLine Industrial Enclosures |
Weight | 7.5 lb |
Package Dimensions (L x W x H) | 63 IN x 3 IN x 3 IN |
Package Dimensions (L x W x H) | 160.02 cm x 7.62 cm x 7.62 cm |
Package Weight (Imperial) | 7.500 L |
Package Weight (Metric) | 3.402 kg |
BX4
Sealable and transparent protective covers BX4 and non-removable BX4-CA to protect the devices against accidental contact.
LT20D-NEW
1/2 Inch, 90 Degree, Two-Piece Liquidtight Non-Metallic Fitting, UL E32447, Temperatures up to 107 Degrees C, Nitril Rubber O-Ring, PVC, Grey
LN43DA
1/2 Inch, Straight, One-Piece Liquidtight Non-Metallic Fitting, CSA, UL E32447, Temperatures up to 60 Degrees C, PVC, Grey
LH38
Cord Grip with NPT Threads, Locknut Included, NPT Thread Size 3/8 Inch, Cable Range 0.181 Inch/4.6mm to 0.312 Inch/7.9mm, Hole Clearance 0.670 Inch/17.0mm, Thread Length 0.53 Inch/13.5mm, IP68 Rating, Nylon, Black
How to Install the PSB16 Panel Support Brace
This guide provides step-by-step instructions for installing the PSB16 Panel Support Brace to ensure proper support for your panel.
Estimated time: 30m
Tools needed:
Screwdriver, Drill
Supplies needed:
Mounting screws, Washers
- Prepare the installation area
Clear the installation area of any obstructions and ensure the surface is clean and dry.
- Mount the support brace
Align the PSB16 support brace with the designated mounting holes on the panel. Use a screwdriver to secure the brace with the provided mounting screws and washers.
- Verify the installation
Check that the support brace is securely mounted and that there is no movement. Ensure all screws are tightened properly.
