Contact for Pricing
Overview
- Conductive steel brace; furnished in pairs
- Braces can be installed on existing systems without removing the panel
- Conductive design for electrical continuity and safety.
- Attaches to frame with BV-M6 fasteners and subpanel with hex bolt.
- Set of 2 brackets with mounting hardware included.
Specifications
Application | Power Distribution; Controls and Drives |
Color | Unpainted |
Finish | Galvanized |
Fits Panel Width | 1,000 mm |
Material | Mild Steel |
Modification Services | Yes |
Product Family | ProLine |
Size | fits 1000mm |
Thickness | 3.04 mm |
Thickness | 11 ga |
Type | Internal Mounting for ProLine Industrial Enclosures |
Weight | 9.1 lb |
Package Dimensions (L x W x H) | 42 IN x 5.5 IN x 4.7 IN |
Package Dimensions (L x W x H) | 106.68 cm x 13.97 cm x 11.938 cm |
Package Weight (Imperial) | 9.100 L |
Package Weight (Metric) | 4.128 kg |
