Overview
- Rack Angles are furnished in pairs
- Rack Angles comply with EIA 310-D rack mounting standards
- Through-holes accommodate English and metric cage nuts
- Complies with ANSI/EIA RS-310-D rack mounting standards
- Furnished in pairs with all necessary mounting hardware
Specifications
Application | Controls and Drives |
Color | Unpainted |
Depth | 4.32 |
Depth | 110 |
Depth | 110 mm |
Finish | Plated |
Height | 312 mm |
Height | 12.27 |
Height | 312 |
Material | Steel |
Material | Mild Steel |
Modification Services | Yes |
Product Family | ProLine |
Rack Units | 7 |
Size | 7U fits Proline in |
Thickness | 1.9 mm |
Thickness | 14 ga |
Type | HMI Enclosure Systems |
Type | Other Accessories |
Weight | 4 lb |
Width | 50 mm |
Width | 1.95 |
Width | 50 |
Works With | NEMA |
Package Dimensions (L x W x H) | 17 IN x 3 IN x 3 IN |
Package Dimensions (L x W x H) | 43.18 cm x 7.62 cm x 7.62 cm |
Package Weight (Imperial) | 4.000 L |
Package Weight (Metric) | 1.814 kg |
How to Install the PRA7TH Controller
This guide provides step-by-step instructions for installing and configuring the PRA7TH Controller on a DIN rail.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the PRA7TH controller to the DIN rail using the integrated clips. Ensure the controller is level and firmly attached.
- Connect the wiring
Use terminal connectors to connect the power supply and input/output wires to the appropriate terminals on the PRA7TH controller. Verify that all connections are secure.
- Configure the controller settings
Power on the PRA7TH controller and access the configuration menu. Set the desired parameters according to your application requirements and save the settings.
- Calibrate the controller
Perform a calibration of the PRA7TH controller by following the on-screen instructions. Ensure that all sensors and inputs are functioning correctly.
