Contact for Pricing
Overview
- Axial fan and finger guard mounted in housing
- Drip-protected, raised cover is removable from the inside of the enclosure
- 115V or 230V versions with lead wires
- 115V power cord option
- Rated UL Type 1; installing this component on an enclosure brings the enclosure rating to UL Type 1
- Includes gasket and mounting hardware
- Includes gasket and mounting hardware
Specifications
Application | Networking, Storage and Data Center |
Color | Light Gray |
Color | Gray |
Color | Grey |
Color Code | RAL 7035 |
Finish | Powder Coated |
Finish | Lt Gray;Powder Coated |
Housing Material | Mild Steel |
IP Rating | IP55 |
IP Rating | IP66 |
Material | Mild Steel |
Modification Services | Yes |
Mounting Type | Field-installation |
Mounting Type | Field-installed on solid tops |
Product Family | ProLine |
Series | ProLine |
Thickness | 14 ga |
Thickness | 1.9 mm |
Thickness | 51.40mm (2.024") |
Type | External Mounting for ProLine Industrial Enclosures |
Voltage AC | 115 V |
Voltage Rating | 115 VAC |
Weight | 8 lb |
Works With | NEMA |
Package Dimensions (L x W x H) | 15 IN x 14.75 IN x 6 IN |
Package Dimensions (L x W x H) | 38.1 cm x 37.465 cm x 15.24 cm |
Package Weight (Imperial) | 8.000 L |
Package Weight (Metric) | 3.629 kg |
How to Install the PPT1C Controller
This guide provides step-by-step instructions for installing and configuring the PPT1C Controller.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the PPT1C controller to the designated mounting surface using the provided mounting screws. Ensure it is level and firmly attached.
- Connect the wiring
Use wire strippers to prepare the wires and connect them to the appropriate terminals on the PPT1C controller. Ensure that all connections are secure to prevent any electrical issues.
- Verify the installation
Power on the PPT1C controller and use a multimeter to check that all connections are functioning correctly. Ensure that the controller is receiving the correct voltage and that there are no short circuits.
