- 12 gauge steel; conductive or white painted finish
- All necessary mounting hardware is included
- Partial Subpanels have flanges on four sides for added strength.
- Panels can be positioned vertically in 25-mm increments, but also can be positioned at any depth in 25-mm increments using depth-mounted grid straps for securing (sold separately)
- Includes all necessary mounting hardware for easy installation
- Vertical positioning in 25mm increments
- Depth adjustable with optional grid straps
- Includes all necessary mounting hardware
Specifications
Application | Controls and Drives; Power Distribution |
Color | White |
Finish | Powder Coated |
Fits Frame | 1400 mm or taller mm |
Material | Steel |
Material | Mild Steel |
Modification Services | Yes |
Mounting Type | Flanged mounting |
Product Family | ProLine |
Series | nVent ProLine G2 |
Size | fits 1400+ x 800mm |
Size | 900x800 mm |
Thickness | 12 ga |
Thickness | 2.66 mm |
Type | Internal Mounting for ProLine Industrial Enclosures |
Weight | 35.54 lb |
Package Dimensions (L x W x H) | 35.5 IN x 30.5 IN x 3 IN |
Package Dimensions (L x W x H) | 90.17 cm x 77.47 cm x 7.62 cm |
Package Weight (Imperial) | 35.540 L |
Package Weight (Metric) | 16.121 kg |
