Overview
- Gasketed covers and air intake filters keep contaminants away
- Removable filters can be cleaned to maintain optimal performance
- Fan and filter package provides up to 600 CFM of filtered air to cool equipment
- Three-point locking handles on all doors provide easy but controlled access; two keys included
- Rack angles are infinitely adjustable from front to rear for positioning flexibility
- Mobile base provides easy placement of cabinet
- Mobile base includes casters, levelers and gland plate
- Levelers and anti-tip bracket secure cabinet to the floor
- Front window door made of 16 or 14 gauge steel with safety glass window
- Solid 16 or 14 gauge steel back door
Specifications
Application | Networking, Storage and Data Center |
Color | Light Gray |
Color | Gray |
Color | Grey |
Color Code | RAL 7035 |
Depth | 31.5 |
Depth | 800 |
Depth | 800 mm |
Finish | Gray;Powder Coating |
Finish | Powder Coated |
Height | 1,999 mm |
Height | 78.7 |
Height | 1,999 |
Material | Mild Steel |
Material | Steel |
Material | Mild Steel;Steel |
Modification Services | Yes |
NEMA Rating | 1 |
NEMA Rating | 1 Indoor, electrical protection |
Product Family | ProLine |
Protection Rating | NEMA Type 1 |
Size | 2000x700x800mm |
Thickness | 12 |
Thickness | 2.66 |
Thickness | 2.66 mm |
Type | Data Networking Freestanding Cabinets |
Weight | 117 lb |
Width | 27.6 |
Width | 701 |
Width | 701 mm |
Package Dimensions (L x W x H) | 83 IN x 33 IN x 27 IN |
Package Dimensions (L x W x H) | 210.82 cm x 83.82 cm x 68.58 cm |
Package Weight (Imperial) | 117.000 L |
Package Weight (Metric) | 53.071 kg |
