Overview
- Description: Aluminium plinth allows cabling without any restrictions. The plinth consists of two lateral profiles with removable front and rear plates.
- Material: Aluminium AlMg3. Profiles: 3 mm and panels 2 mm.
- Finish: RAL 7035 polyester powder coated.
- Pack quantity: 1 plinth with mounting material.
- Provides a stable, elevated foundation for industrial enclosures.
Specifications
Color | Gray |
Color Code | RAL 7035 |
Depth | 500 mm |
Depth | 19.69 in |
Enclosure Material | Aluminum |
Height | 44 IN |
Height | 3.94 in |
Material | Aluminum |
Product Family | Free-Standing |
Type | Fixing |
Width | 70.87 in |
Width | 1,800 mm |
Works With | IEC |
Package Dimensions (L x W x H) | 71.24 IN x 4.31 IN x 71.49 IN |
Package Dimensions (L x W x H) | 180.9496 cm x 10.9474 cm x 181.5846 cm |
Package Weight (Imperial) | 33.800 L |
Package Weight (Metric) | 15.332 kg |
TC150
Universal raintight hubs are rated for outdoor enclosures and come in a variety of sizes for every ABB load center or panel. The TC150 has a diameter of 1.50" and has a base size of 3".
H8064HLL
8x6x4 Polycarbonate Enclosure NEMA 4X | Hinged Cover | Gray | Stainless Steel Locking Latch | Mounting Feet
RC75
Non-metallic snap style Romex connector for confined and tight areas. It is made of heat treated carbon steel with a bright finish. The connector is sized for one cable and is listed for 14/2, 12/2, 10/2, 14/3, 12/3, and 10/3 cable.
Frequently Asked Questions
What are the dimensions of the PFAL1185 plinth?
The plinth has a height of 3.94 inches, a width of 70.87 inches, and a depth of 19.69 inches.
What material is the PFAL1185 plinth made of?
The plinth is constructed from Aluminium AlMg3 with profiles of 3 mm and panels of 2 mm.
What is the finish of the PFAL1185 plinth?
The plinth has a RAL 7035 polyester powder coated finish.
What is the color of the PFAL1185 plinth?
The plinth is Light Gray, with the color code RAL 7035.
What is the product family for PFAL1185?
The PFAL1185 belongs to the Free-Standing product family.
How does the plinth facilitate cabling?
The aluminium plinth allows for unrestricted cabling by creating extra space underneath the enclosure.
What is the pack quantity for the PFAL1185 plinth?
The pack quantity includes 1 plinth with the necessary mounting material.
What are the installation requirements for nVent products?
nVent products must be installed and used only as indicated in nVent's product instruction sheets and training materials.
Are there any special notes about the 1800 mm wide plinth?
Yes, the 1800 mm wide plinth is made of two pieces.
How to Install the Front PFAL Plinth
This guide details the installation of the front PFAL plinth, including fastener types, quantities, and required torque specifications for proper assembly.
Estimated time: 15m
Tools needed:
SW8 wrench, T30 Torx bit, Torque wrench
Supplies needed:
M10x25 bolts (4), M6x16 bolts (2), M10 nuts/washers (4)
- Position the Front PFAL Plinth
Carefully align and position the front PFAL plinth onto the main unit, ensuring all mounting holes are correctly aligned with the corresponding attachment points.
- Install M10 Components
Place the four M10 components (C), which are likely nuts or washers, into their designated positions to prepare for the main bolts. Ensure they are seated correctly.
- Secure with M6x16 Bolts
Insert and hand-tighten the two M6x16 bolts (B) into their respective holes. Using an SW8 wrench, tighten these bolts to a final torque of 8-10 Nm. Do not overtighten.
- Secure with M10x25 Bolts
Insert and hand-tighten the four M10x25 bolts (A) into their respective holes. Using a T30 Torx bit and a torque wrench, tighten these bolts to a final torque of 10-15 Nm. Ensure even tightening across all bolts.
