Overview
- Solenoids are rated for continuous duty and will stand up under heavy industrial use
- Packaged complete with a solenoid assembly, mounting bracket and instructions for field installation
- Door handles and latching mechanisms are not included
- Installation: Interlock mounts on bracket attached to door bar on inside of enclosure door.
- Maintains UL Type 4, 4X, and 12 ratings when properly installed
Specifications
A @ 110 V/50 Hz Normal Inrush | 0.120 / 0.69 A |
A @ 110 V/50 Hz Normal Inrush | .120/.69 A |
A @ 120 V/60 Hz Normal Inrush | 0.100 / 0.63 A |
A @ 120 V/60 Hz Normal Inrush | .100/.63 A |
Application | Arc Flash Safety;Controls and Drives;Power Distribution |
Application | Power Distribution; Controls and Drives; Arc Flash Safety |
Color | Unpainted |
Current Rating | 0.100/0.63 A |
Finish | Plated |
Frequency | 60 Hz |
Material | Mild Steel;Steel |
Material | Mild Steel |
Material | Steel |
Modification Services | Yes |
Nema Rating | Type 4, Type 4X, Type 12, Type 1 |
Product Family | ProLine |
Series | AE K Series |
Series | AE K115, AE K230, AE K460 |
Type | External Mounting for Industrial Enclosures |
Voltage Rating | 120 VAC |
Weight | 1.6 lb |
Works With | NEMA |
Package Dimensions (L x W x H) | 5.2 IN x 3.9 IN x 2.9 IN |
Package Dimensions (L x W x H) | 13.208 cm x 9.906 cm x 7.366 cm |
Package Weight (Imperial) | 1.600 L |
Package Weight (Metric) | 0.726 kg |
