Overview
- Install easily on front or rear of enclosure frame; can be hinged on left or right
- Have two grounding brackets
- Have a .25-in.-thick window that provides maximum protection and viewing area
- Have foam-in-place urethane gaskets for door and window to provide optimum sealing
- Designed for front or rear mounting on nVent ProLine frames.
Specifications
Application | Controls and Drives |
Color | Light Gray |
Color Code | RAL 7035 |
Finish | Powder Coated |
Fits Frame | 2000 x 700 mm |
Material | Aluminum, Glass, Mild Steel |
Material | Mild Steel |
Modification Services | Yes |
Mounting Type | Front or rear mounting |
Product Family | ProLine |
Safety Glass | 76.34 x 27.28 in |
Safety Glass | 1939 x 693 mm |
Series | ProLine |
Size | fits 2000x700mm |
Size | 2000x700mm |
Thickness | 1.9 mm |
Thickness | 14 ga |
Type | External Mounting for ProLine Industrial Enclosures |
Weight | 55 lb |
Window Door Type | Mild Steel and Safety Glass |
Window Size | 1818 x 546 mm |
Window Size | 71.56 x 21.48 in |
Package Dimensions (L x W x H) | 79 IN x 33 IN x 2.75 IN |
Package Dimensions (L x W x H) | 200.66 cm x 83.82 cm x 6.985 cm |
Package Weight (Imperial) | 55.000 L |
Package Weight (Metric) | 24.948 kg |
