Contact for Pricing
Overview
- Doors are hinged at lower edge and have quarter-turn latches
- Ground stud and mounting hardware
- Light gray steel construction with RAL 7035 textured polyester powder paint
- Quarter-turn latch system with 95-degree stop arm for hands-free operation
- Seamless polyurethane gasket for watertight and dust-tight seal
Specifications
Application | Controls and Drives |
Color | LtGray |
Color | Light Gray |
Color Code | RAL 7035 |
Depth | 22.23 |
Depth | 565 |
Depth | 565 mm |
Door Size | 19.86 x 31.17 in |
Door Size | 504 x 792 mm |
Finish | Powder Coated |
Height | 500 mm |
Height | 19.69 |
Height | 500 |
Material | Steel |
Material | Mild Steel |
Modification Services | Yes |
Mounting Type | Hinged at lower edge with quarter-turn latches |
Product Family | ProLine |
Size | fits 507/682x800mm |
Size | 507/682x800mm |
Thickness | 1.52 mm |
Thickness | 16 ga |
Type | HMI Enclosure Systems |
Type | Other Accessories |
Weight | 16 lb |
Width | 31.5 |
Width | 800 |
Width | 800 mm |
Window Size | 362 x 635 mm |
Window Size | 14.25 x 25.00 in |
Works With | NEMA |
Package Dimensions (L x W x H) | 33 IN x 22.5 IN x 2.5 IN |
Package Dimensions (L x W x H) | 83.82 cm x 57.15 cm x 6.35 cm |
Package Weight (Imperial) | 16.000 L |
Package Weight (Metric) | 7.258 kg |
How to Install the PDW58F Controller
This guide provides step-by-step instructions for installing and configuring the PDW58F Controller, ensuring proper wiring and setup.
Estimated time: 45m
Tools needed:
Screwdriver, Wire strippers, Multimeter
Supplies needed:
Mounting screws, Terminal connectors
- Mount the controller
Secure the PDW58F controller to the designated mounting surface using the provided mounting screws. Ensure that it is level and firmly attached.
- Connect the wiring
Use wire strippers to prepare the wires and connect them to the appropriate terminals on the PDW58F controller. Ensure that connections are tight and secure to prevent any electrical issues.
- Verify the connections
Utilize a multimeter to check the voltage and continuity of the connections. Confirm that all connections are correct and functioning before powering on the controller.
- Power on the controller
Once all connections are verified, power on the PDW58F controller and observe the indicator lights to ensure it is operating correctly.
- Configure the settings
Access the configuration menu on the PDW58F controller and input the necessary settings according to your application requirements.
- Calibrate the controller
Follow the calibration procedure outlined in the user manual to ensure the PDW58F controller is accurately measuring and responding to inputs.
